Sunrise Medical Swing-Away and Fixed Front GTX - Manual (Page 114)

[Revision: 01/2007]
PAGE 114 QUICKIE GTX
Pos. Item Number Description Remarks
1 542160 FORK EXT WLDMT TRVL WHEEL Q2
2 202102 5/16-18 NYLOCK NUT THIN
3 263100 5/16 AN WASHER FLAT
4 052071 TRAVEL WHEEL UPPER WELD ASSM
5 330027 QUICK RELEASE PIN 1/4"
6 561018 1" TUBE END BUSHING THICK
7 226190 5/16-18 X 1 3/4 BH C/S SHLDR
8 920025 3" MICRO CASTER W/BRNG (PR)
9 XM2138 CABLE STEEL BLK PV COATED
10 XM2139 TERMINAL ALUM OVAL SLEEVE
11 052116 RECEIVER ANTI-TIP
12 230011 SHCS M6 X 1 X 20 BLK
13 050129-001 LOCKWASHER HIGH COLLAR M6
14 052151 PLATE ADAPTER ANTI TIP
1-3,7,8 100849 ASSY FORK EXT TRAVEL WHEEL
1-14 102156 TRAVEL WHL ASSM W/RECEIVERS
