QUICKIE GTX PAGE 15
CASTER LOCK PIN
Pos. Item Number Description Remarks
1A 052310-001 BLOCK ASSY CSTR PIN LCK R STD
1B 052311-001 BLOCK ASSY CSTR PIN LCK L STD
1C 052310-002 BLOCK ASSY CSTR PIN LCK R+.5
1D 052311-002 BLOCK ASSY CSTR PIN LCK L +.5
1E 052310-003 BLOCK ASSY CSTR PIN LOCK R+1
1F 052311-003 BLOCK ASSY CSTR PIN LCK +1
2 050047 PLATE CASTER LOCK ANG ADJ
3 050050 KEY CASTER LOCK ANG ADJ
4 050053 SADDLE 17.8MM OD 8MM HOLE
5 050133 SHOULDER SCREW 8MMOD X 35MM LG
6 052172 YOKE CASTER PIN LOCK
7 230496 M5-12 FH C/S BLK
1A,2-7 102149-001 ASSY CASTER PIN LOCK R STD
1B,2-7 102149-002 ASSY CASTER PIN LOCK R +.5
1C,2-7 102149-003 ASSY CASTER PIN LOCK R +1
1D,2-7 102150-001 ASSY CASTER PIN LOCK L STD
1E,2-7 102150-002 ASSY CASTER PIN LOCK L +.5
1F,2-7 102150-003 ASSY CASTER PIN LOCK L +1
