QUICKIE GTX PAGE 39
FOLDING BACKREST HARDWARE
Note: for chairs built prior to July 20 2007 S/N F3­134556 you must replace both backrest brackets by ordering 103542­001 or 103542­002.
Pos. Item Number Description Remarks
1 103470 WASHER PIVOT BACKREST
2 050017 PIN PLUNGER BACKREST
3 102262-007 BHCS M6 X 1 X 45 INORGANIC
4 102262-002 BHCS M6 X 1 X 10 W/PL INORG
5A 103490-003 BRACKET BACKREST 22MM
5B 103490-004 BRACKET BACKREST 22MM EXT For use with solid back insert
6 103679 SLEEVE BRACKET BACKREST .088 Used on non-heavy duty chairs
7 103238 CAM STOP BACKREST
8 200113 NUT HEX NYLOCK M6 X 1 NUT
9 250104 WASHER FLAT M6
10 050020 SPRINGCOMP.312OD1.131G.025WSS
11 342015 LANYARD ATTACH RING
12 750060 BACK REL STRAP 12"-22" RIGID
