Name Quantity
4-channel Network DVR 1
IR Remote Control 1
Power Cable 1
Power Adaptor 1
BNC to RCA Female Adaptors 5
Hard Drive Tray and 2 Keys 1
Remote Viewing Software 1
User Manual 1
If any of these components are missing please contact your retailer
2
Contents list
6. Playback ....... ....... .. 23
7. Search Play ...... ....... ....... .. 23
8. Time Search ....... ... ....... .. 24
9. Event Search ....... ....... .. .. 25
10. Start Stop Search ....... ....... .. 25
11. Zoom Operation ....... ....... .. 26
12. PIP Operation ....... ....... .. 26
13. Information Display ....... ....... ... 27
14. Default Setting ....... ....... .. 27
1 . ....... ....... .. 2
1 . Remote Control ....... ....... .. 29
1 . Serial Port Control ....... ....... .. 29
1 . PC View Software Operation ....... ....... 29
Appendix A: Trouble shooting guide ..... 33
Appendix B: Serial port protocol .. 35
Appendix C: Record Time Table ..... . 37
Specifications ....................38
Exterior ....................38
.......................................... ..................... ........... ........................
................................ ............. ..................... ........... ............
.............................................. .................. ... ........... ............
............................................. ..................... .......... . .............
............................................... ..................... ........... .......
............................................... ..................... ........... .......
.............................................. ..................... ........... .............
............................................... ..................... ........... ...
............................................. ..................... ........... .............
5 Menu Option Table..................................... ..................... ........... ............. 8
6 ............................................. ..................... ........... ..........
7 .............................................. ..................... ........... ......
8 ............................................... ..................... ..
........................................................
................................................................. .
.......................................................... .... .
................................................................................
Dimensions.......................................................................
37
PTC4: (eight byte)
Note: This protocol is the same as PELCO-P's call function; you can use PELCO-P's call
function to control the DVR. First, you must set right protocol, baud rate and address, second,
you push the call button on the keypad, then enter the number according to the Var table
above, then push the enter button.
Note: The above figures are from our test results using a default setup, and are for the users
reference. Actual recording times may vary depending on hard disk size, subject complexity,
camera resolution and movement within the frame.
Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 Byte8
0xa0 Addr 0x00 0x07 0x00 Var 0xAF Checksum
Byte8 = byte1 xor byte2 xor byte3 xor byte4 xor byte5 xor byte6 xor byte7
Var Function Var Function
0x01 Ch1/up 0x0C Schedule
0x02 Ch2/down 0x0D 0/next field
0x03 Ch3/left 0x0E 1/auto
0x04 Ch4/right 0x0F 2/zoom
0x05 Chall/enter 0x10 3/PIP
0x06 record 0x11 4/trip
0x07 Play 0x12 5/stop
0x08 Pause 0x13 6/search
0x09 Reward 0x14 7/WM/add
0x0A Forward 0x15 8/display/DEC
0x0B Menu 0x16 9/previous field
Appendix C: record time for 40GB hard disk (hours)
Rec rate field/sec Picture quality Resolution Recording time
50 fps Very high 720 7.5 hours
50 fps Low 720 20 hours
25 fps Normal 360 24 hours
25 fps Low 360 67 hours
1 fps Normal 720 720 hours
