Swann DVR16-8600 User Manual
Swann Car DVR
www.swannsecurity.com
Swann Communications • Toll Free Technical Support: USA - 1-800-627-2799, 1-877-274-3695, Australia - 1300 13 8324 • Email: [email protected]
DVR16-8600 Kit - Easy Setup Guide
Stand Adjustment
C
Back of DVR
Back of TV
INPUT
Connect the yellow
RCA cable to an INPUT
on the back of your TV
1
Connect the BNC end
of the cable to the top
VIDEO INPUT on DVR
2
Tune your TV to the correct INPUT - this
is sometimes labelled A/V, input, source,
L1, L2, etc. - consult TV manual for details
3
B
Camera Connections
Connect camera
cables to white
Extension Cables x 8
1
Connect all 8 white power
ends of Extension cables to
the 2 Power Splitters
2
Connect Power
Splitters to Camera
Power Adapters
3
Plug in Camera Power
Adpaters and DVR
Adapter to outlets
4
Connect BNC Extension
to back of DVR in ports
marked 1-8
Legend
Power Connections
Video Connections
5
Package Contents
A
CCD MaxiBrite
Cameras x 8
Extension Cables x 8
Security
Stickers
Power Splitter x 2
Camera Power
Supply x 2
DVR Power
Supply
DVR
BNC to
RCA Cable
Power Cable for
DVR Power Supply
User Manual
