Communication via Ethernet CPs in S7 Stations
34
SIMATIC NET NCM S7 for Industrial Ethernet
C79000-G8976-C129–06
1.7.2 Network/Project Variant: SIMATIC S5 and Non-SIMATIC Devices
on the Subnet
Configuration of the System
In addition to SIMATIC S7 stations, SIMATIC S5 stations and non-SIMATIC
devices can be included in your system.
Ethernet (1)
System
“Production”
SIMATIC S5
Non-SIMATIC
S7-400/1
S7-300/1
S7-300/2
SIMATIC S5 stations you intend to include in the communication can be
selected directly. Non-SIMATIC devices must be entered in the configuration as
Other stations.
View in a STEP 7 Project
