Programming FCs (Functions) and FBs for S7 Ethernet CPs
166
SIMATIC NET NCM S7 for Industrial Ethernet
C79000-G8976-C129–06
Table 5-3 AG_RECV / AG_LRECV Codes
NDR Meaning STATUS ERROR
0 1 8304
H
The connection is not established. The send job should only be
attempted again after waiting for at least 100 ms.
0 1 8F23
H
Source area invalid, for example:
Area does note exist in the DB.
0 1 8F25
H
Area error writing a parameter.
0 1 8F29
H
Alignment error writing a parameter.
0 1 8F30
H
Parameter is in the write-protected 1st act. data block.
0 1 8F31
H
Parameter is in the write-protected 2nd act. data block.
0 1 8F32
H
Parameter contains a DB number that is too high.
0 1 8F33
H
DB number error.
0 1 8F3A
H
Destination area not loaded (DB).
0 1 8F43
H
Timeout writing a parameter to the I/O area.
0 1 8F45
H
Address of the parameter to be read is disabled in the access
track.
0 1 8F7F
H
Internal error, e.g. illegal ANY reference.
0 1 8090
H
No module with this address exists or the CPU is in the STOP
mode.
0 1 8091
H
Logical base address not at a double word boundary.
0 1 8092
H
In the ANY reference, a type other than BYTE is specified.
(S7-400 only)
0 1 80A0
H
Negative acknowledgment reading from the module.
0 1 80A4
H
The communication bus connection between the CPU and CP is
not established.
0 1 80B0
H
The module does not recognize the data record.
0 1 80B1
H
Destination area invalid.
0 1 80B2
H
The communication bus connection between the CPU and CP is
not established.
0 1 80C0
H
The data record cannot be read.
0 1 80C1
H
The specified data record is currently being processed.
0 1 80C2
H
There are too many jobs pending.
0 1 80C3
H
CPU resources (memory) occupied.
0 1 80C4
H
Communication error (occurs temporarily and a repetition in the
user program will often remedy the problem).
0 1 80D2
H
Module base address incorrect.
