Engine 710J
For use both in and outside U.S., Canada, and Europe
manufacturer and model . . . . . . . . . . . . . . . . . . . . John Deere PowerTech Tm E 6068HT067 turbocharged, standard
Non-Road Emissions Standard . . . . . . . . . . . . . . . . EPA Tier 3/EU Stage IIIA
Displacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.8 L (414 cu. in.)
Net Peak Power (ISO9249) . . . . . . . . . . . . . . . . . . . 94 kW (126 hp) @ 2,000 rpm
Net Peak Torque (ISO9249) . . . . . . . . . . . . . . . . . . 549 Nm (404 lb.-ft.) @ 1,300 rpm
Net Torque Rise . . . . . . . . . . . . . . . . . . . . . . . . . . . 38%
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pressure system with spin-on filter and cooler
Air Cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . dual-stage dry type with safety element and evacuator valve
Cooling
Fan Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . suction
Engine Coolant Rating . . . . . . . . . . . . . . . . . . . . . . –37 deg. C (–34 deg. F)
Engine Oil Cooler . . . . . . . . . . . . . . . . . . . . . . . . . . oil to water
Powertrain
Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-speed, helical-cut gears, full PowerShift Tm with hydraulic reverser standard; electric clutch cutoff on loader lever
Torque Converter . . . . . . . . . . . . . . . . . . . . . . . . . single stage, dual phase with 1.95:1 stall ratio; 280 mm (11 in.)
maximum Travel Speeds with Standard
Engine and 21L-28 Rear Tires . . . . . . . . . Forward Reverse
With 15-19.5 Front Tires and
mechanical-Front-Wheel Drive
Gear 1 . . . . . . . . . . . . . . . . . . . . . . . . 6.1 km/h (3.8 mph) 6.9 km/h (4.3 mph)
Gear 2 . . . . . . . . . . . . . . . . . . . . . . . . 10.3 km/h (6.4 mph) 11.4 km/h (7.1 mph)
Gear 3 . . . . . . . . . . . . . . . . . . . . . . . . 24.9 km/h (15.5 mph) 27.5 km/h (17.1 mph)
Gear 4 . . . . . . . . . . . . . . . . . . . . . . . . 36.0 km/h (22.4 mph) N/A
With 14.5/75-16.1 Front Tires
Gear 1 . . . . . . . . . . . . . . . . . . . . . . . . 6.1 km/h (3.8 mph) 6.9 km/h (4.3 mph)
Gear 2 . . . . . . . . . . . . . . . . . . . . . . . . 10.3 km/h (6.4 mph) 11.6 km/h (7.2 mph)
Gear 3 . . . . . . . . . . . . . . . . . . . . . . . . 24.9 km/h (15.5 mph) 27.7 km/h (17.2 mph)
Gear 4 . . . . . . . . . . . . . . . . . . . . . . . . 36.0 km/h (22.4 mph) N/A
Axles
Axle Oscillations, Stop to Stop (both axles) . . . . 22 deg.
Axle Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . Mechanical-
Standard front-wheel drive Rear
Static . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 950 kg 18 500 kg 19 700 kg
(50,596 lb.) (40,786 lb.) (43,431 lb.)
Dynamic . . . . . . . . . . . . . . . . . . . . . . . . . . 9200 kg 7700 kg 9800 kg
(20,283 lb.) (16,976 lb.) (21,605 lb.)
Ultimate . . . . . . . . . . . . . . . . . . . . . . . . . . 41 000 kg 43 600 kg 46 400 kg
(90,390 lb.) (96,122 lb.) (102,295 lb.)
Differentials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . hydraulic locking rear, electric, foot-actuated; limited slip front
Steering (ISO5010) . . . . . . . . . . . . . . . . . . . . . . . . hydrostatic power and emergency steering
Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mechanical-
front-wheel drive Non-powered front
Curb-Turning Radius
With Brakes . . . . . . . . . . . . . . . . . . . . 4.05 m (13 ft. 3 in.) 4.07 m (13 ft. 4 in.)
Without Brakes . . . . . . . . . . . . . . . . . 4.62 m (15 ft. 2 in.) 4.65 m (15 ft. 3 in.)
Bucket Clearance Circle
With Brakes . . . . . . . . . . . . . . . . . . . . 11.04 m (36 ft. 3 in.) 11.31 m (37 ft. 1 in.)
Without Brakes . . . . . . . . . . . . . . . . . 12.07 m (39 ft. 7 in.) 12.31 m (40 ft. 5 in.)
Steering Wheel Turns (lock to lock,
flow amplified) . . . . . . . . . . . . . . . . . . 2.7 to 4.4 2.8 to 4.5
Final Drive
mechanical-Front Wheel . . . . . . . . . . . . . . . . . heavy-duty, inboard planetary final drives distribute shock loads over 3 gears
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . heavy-duty, inboard planetary final drives distribute shock loads over 4 gears
