410J 410J
410J
Engine 410J
For use in U.S., Canada, and Europe For use outside U.S., Canada, and Europe
manufacturer and model . . . . . . . . . . . . . . . . . . . . John Deere PowerTech Tm E 4045HT054 turbocharged, standard John Deere 4045T PowerTech turbocharged, standard*
Non-Road Emissions Standard . . . . . . . . . . . . . . . . EPA Tier 3/EU Stage IIIA EPA Tier 2/EU Stage II
Displacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.5 L (276 cu. in.) 4.5 L (276 cu. in.)
Net Peak Power (ISO9249) . . . . . . . . . . . . . . . . . . . 73 kW (98 hp) @ 2,000 rpm 72 kW (96 hp) @ 2,100 rpm
Net Peak Torque (ISO9249) . . . . . . . . . . . . . . . . . . 416 Nm (306 lb.-ft.) @ 1,300 rpm 378 Nm (278 lb.-ft.) @ 1,500 rpm
Net Torque Rise . . . . . . . . . . . . . . . . . . . . . . . . . . . 47% 26%
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pressure system with spin-on filter and cooler pressure system with spin-on filter and cooler
Air Cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . dual-stage dry type with safety element and evacuator valve dual-stage dry type with safety element and evacuator valve
*This engine not available on 410J TMC.
Cooling
Fan Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . suction
Engine Coolant Rating . . . . . . . . . . . . . . . . . . . . . . –37 deg. C (–34 deg. F)
Engine Oil Cooler . . . . . . . . . . . . . . . . . . . . . . . . . . oil to water
Powertrain
Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-speed, helical-cut gears, full PowerShift Tm with hydraulic reverser standard; electric clutch cutoff on loader lever
Torque Converter . . . . . . . . . . . . . . . . . . . . . . . . . single stage, dual phase with 2.63:1 stall ratio; 280 mm (11 in.)
maximum Travel Speeds with Standard
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . Forward Reverse
Gear 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.9 km/h (3.7 mph) 7.4 km/h (4.6 mph)
Gear 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . 10.8 km/h (6.7 mph) 13.6 km/h (8.5 mph)
Gear 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . 21.9 km/h (13.6 mph) 21.6 km/h (13.4 mph)
Gear 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . 37.4 km/h (23.2 mph) N/A
Axles
Axle Oscillations, Stop to Stop (both axles) . . . . 22 deg.
Axle Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . Mechanical-
Standard front-wheel drive Rear
Static . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 000 kg 12 000 kg 13 000 kg
(39,683 lb.) (26,455 lb.) (28,660 lb.)
Dynamic . . . . . . . . . . . . . . . . . . . . . . . . . . 7200 kg 6000 kg 7000 kg
(15,873 lb.) (13,228 lb.) (15,432 lb.)
Ultimate . . . . . . . . . . . . . . . . . . . . . . . . . . 32 950 kg 28 200 kg 30 600 kg
(72,642 lb.) (62,170 lb.) (67,461 lb.)
Differentials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . hydraulic locking rear, electric, foot actuated; limited slip front
Steering (ISO5010) . . . . . . . . . . . . . . . . . . . . . . . . hydrostatic power and emergency steering
Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mechanical-
front-wheel drive Non-powered front
Curb-Turning Radius
With Brakes . . . . . . . . . . . . . . . . . . . . . . . 3.58 m (11 ft. 9 in.) 3.44 m (11 ft. 4 in.)
Without Brakes . . . . . . . . . . . . . . . . . . . . . 4.08 m (13 ft. 5 in.) 3.94 m (12 ft. 11 in.)
Bucket Clearance Circle
With Brakes . . . . . . . . . . . . . . . . . . . . . . . 10.11 m (33 ft. 2 in.) 9.89 m (32 ft. 5 in.)
Without Brakes . . . . . . . . . . . . . . . . . . . . . 11.05 m (36 ft. 3 in.) 10.76 m (35 ft. 4 in.)
Steering Wheel Turns (lock to lock, flow
amplified) . . . . . . . . . . . . . . . . . . . . . . . . . 2.6 to 3.6 3.1 to 4.4
Final Drive
mechanical-Front Wheel . . . . . . . . . . . . . . . . . heavy-duty, outboard planetary final drives distribute shock loads over 3 gears
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . heavy-duty, outboard planetary final drives distribute shock loads over 4 gears
Brakes (conform to ISO 3450)
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . power assisted, hydraulic wet disc, mounted inboard, self-adjusting and self-equalizing
Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . spring-applied, hydraulically released, wet, multi disc, independent of service brakes with electric switch control
