Hydraulics 310SJ TMC
main Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pressure-compensated load-sensing (PCLS) axial piston
Pump Flow @ 2,200 rpm
Backhoe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159 L/m (42 gpm)
Loader. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159 L/m (42 gpm)
System Relief Pressure
Backhoe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 993 kPa (3,625 psi)
Loader. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 993 kPa (3,625 psi)
Backhoe Controls . . . . . . . . . . . . . . . . . . . . . . . . . TmC electrohydraulic controls standard; auxiliary functions optional
Loader Controls . . . . . . . . . . . . . . . . . . . . . . . . . . TmC electrohydraulic controls standard; auxiliary function and TmC tool carrier optional
Cylinders
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . heat-treated, chrome-plated, polished rods; hardened-steel (replaceable bushings) pivot pins
Bore Rod Diameter Stroke
Loader Boom (2) . . . . . . . . . . . . . . . . . . . . . . . . . 80 mm (3.15 in.) 50 mm (1.97 in.) 790 mm (31.10 in.)
Tool-Carrier Option (2) . . . . . . . . . . . . . . . . . 90 mm (3.54 in.) 50 mm (1.97 in.) 672.9 mm (26.49 in.)
Loader Bucket (1) . . . . . . . . . . . . . . . . . . . . . . . . 90 mm (3.54 in.) 50 mm (1.97 in.) 744 mm (29.29 in.)
Tool-Carrier Option (1) . . . . . . . . . . . . . . . . . 100 mm (3.94 in.) 56 mm (2.20 in.) 729.8 mm (28.73 in.)
Backhoe Boom (1) . . . . . . . . . . . . . . . . . . . . . . . . 120 mm (4.72 in.) 56 mm (2.20 in.) 795 mm (31.30 in.)
Backhoe Crowd (1) . . . . . . . . . . . . . . . . . . . . . . . 115 mm (4.53 in.) 63 mm (2.48 in.) 602.5 mm (23.72 in.)
Backhoe Bucket (1) . . . . . . . . . . . . . . . . . . . . . . . 100 mm (3.94 in.) 63 mm (2.48 in.) 810 mm (31.89 in.)
Backhoe Swing (2). . . . . . . . . . . . . . . . . . . . . . . . 90 mm (3.54 in.) 50 mm (1.97 in.) 278 mm (10.94 in.)
Backhoe Extendable Dipperstick (1) . . . . . . . . . 70 mm (2.76 in.) 40 mm (1.57 in.) 1067 mm (42.01 in.)
Backhoe Stabilizer
Standard (2) . . . . . . . . . . . . . . . . . . . . . . . . . 90 mm (3.54 in.) 50 mm (1.97 in.) 500 mm (19.69 in.)
Longer Optional (2) . . . . . . . . . . . . . . . . . . . . 100 mm (3.94 in.) 50 mm (1.97 in.) 500 mm (19.69 in.)
Non-Powered Axle (1) . . . . . . . . . . . . . . . . . . . . . 70 mm (2.76 in.) 42 mm (1.65 in.) 213 mm (8.39 in.)
Mechanical-Front-Wheel Drive (1) . . . . . . . . . . . 67 mm (2.64 in.) 42 mm (1.65 in.) 210 mm (8.27 in.)
Electrical
Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 volt
Alternator Rating . . . . . . . . . . . . . . . . . . . . . . . . . . 120 amp
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 halogen: 2 front and 2 rear (32,500 candlepower each); turn signals and flashers 2 front and 2 rear; stop and tailights and 2 rear reflectors
Operator Station
Type (SAE J1040) . . . . . . . . . . . . . . . . . . . . . . . . . canopy, isolation mounted, ROPS/FOPS, left/right access, with molded roof
Tires/Wheels
Front Rear
Non-Powered Front Axle . . . . . . . . . . . . . . . . . . . . 11L-16 SL F-3 (12) 19.5L-24 R-4 (10)
mechanical-Front-Wheel Drive . . . . . . . . . . . . . . . . 12.5/80-18 I-3 (10) 19.5L-24 R-4 (10)
340/80R18 XmCL 500/70R24 XmCL
Serviceability
Hydraulic Oil Filter, Spin-On Enclosed Replace-
able Element, Vertically mounted . . . . . . . . . . 6-micron filtration / 1,000 service hours
Refill Capacities
Cooling System . . . . . . . . . . . . . . . . . . . . . . . . 25 L (26 qt.)
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 L (19 qt.)
Engine Oil (including vertical spin-on filter) . . . . 13 L (14 qt.)
Torque Converter and Transmission . . . . . . . . 15 L (16 qt.)
Fuel Tank (with ground-level fueling) . . . . . . . 155 L (41 gal.)
Hydraulic System . . . . . . . . . . . . . . . . . . . . . . 91 L (24 gal.)
Hydraulic Reservoir . . . . . . . . . . . . . . . . . . . . . 39 L (10.2 gal.)
mechanical-Front-Wheel-Drive Housing
Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.5 L (7 qt.)
Planetary (each) . . . . . . . . . . . . . . . . . . . . 1 L (1 qt.)
See page 20 for Engine, Cooling, and Powertrain information.
