30–31
A'
B'
C'
D'
SWING PIVOT SWING PIVOT
DIPPER
LIFT
WITH
BOOM
AT 60 °
BOOM
LIFT
SWING PIVOT
DIPPER
LIFT
WITH
BOOM
AT 60 °
BOOM
LIFT
0 4 8 12 16 20
0 1 2 3 4 5 6 7
FEET
METERS 0 4 8 12 16 20
0 1 2 3 4 5 6 7
FEET
METERS FEET
METERS
12
8
4
0
4
8
12
12
8
4
0
4
8
12
12
8
4
0
4
8
12
0 4 8 12 16 20 24
0 1 2 3 4 5 6 7 8
4
3
2
1
0
1
2
3
4
4
3
2
1
0
1
2
3
4
4
3
2
1
0
1
2
3
4
1344 (2,962)
1356 (2,989)
1340 (2,954)
1312 (2,893)
1280 (2,823)
1247 (2,750)
1216 (2,680)
1186 (2,614)
1160 (2,558)
1143 (2,519)
1135 (2,503)
1150 (2,536)
2210
(4,872)
2249 (4,959)
2470 (5,446)
924 (2,036)
943 (2,079)
947 (2,088)
945 (2,084)
939 (2,071)
931 (2,053)
914 (2,014)
921 (2,031)
906 (1,997)
902 (1,988)
902 (1,988)
912 (2,010)
935 (2,062)
1529 (3,371)
1541 (3,398)
1606 (3,541)
1742 (3,841)
2023 (4,459)
1565 (3,450) 1567 (3,454)
1577 (3,467)
1555 (3,428)
1527 (3,366)
1492 (3,289)
1456 (3,210)
1422 (3,136)
1389 (3,062)
1365 (3,010)
1346 (2,967)
1340 (2,954)
1359 (2,997)
2492 (5,494)
2447 (5,394)
2746 (6,055)
BOOM
LIFT
DIPPER
LIFT
WITH
BOOM
AT 60 °
1490 (3,284) 1247 (2,749)
2311 (5,094) 2565 (5,655)
Lift capacities are over-end values in kg (lb.) according to SAE J31. Figures listed are 87% of the maximum lift force available. Base vehicle includes counterweight.
410J Backhoe with Standard Dipperstick
410J Backhoe with 1.22-m (4 ft.)
Extendable Dipperstick, Retracted
410J Backhoe with 1.22-m (4 ft.)
Extendable Dipperstick, Extended
For more detailed spec information and available options, log on to www.JohnDeere.com.
Loader Dimensions / Performance
( See page 29 for line art) 410J
P Bucket Dump Angle (maximum) . . . . . . . . . . . . 45 deg.
Q Rollback Angle at Ground Level . . . . . . . . . . . . 40 deg.
Heavy-duty long lip Heavy-duty Heavy-duty Multipurpose
Bucket Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.96 m 3 (1.25 cu. yd.) 1.00 m 3 (1.31 cu. yd.) 1.15 m 3 (1.50 cu. yd.) 1.00 m 3 (1.31 cu. yd.)
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2184 mm (86 in.) 2337 mm (92 in.) 2388 mm (94 in.) 2337 mm (92 in.)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 405 kg (892 lb.) 521 kg (1,148 lb.) 548 kg (1,208 lb.) 817 kg (1,800 lb.)
Breakout Force . . . . . . . . . . . . . . . . . . . . . . . . . . . 45.4 kN (10,210 lb.) 45.8 kN (10,300 lb.) 45.2 kN (10,170 lb.) 42.9 kN (9,650 lb.)
Lift Capacity (full height) . . . . . . . . . . . . . . . . . . . . 3332 kg (7,340 lb.) 3269 kg (7,200 lb.) 3210 kg (7,070 lb.) 2996 kg (6,600 lb.)
R Height to Bucket Hinge Pin (maximum) . . . . . . . 3.35 m (11 ft. 0 in.) 3.35 m (11 ft. 0 in.) 3.35 m (11 ft. 0 in.) 3.35 m (11 ft. 0 in.)
S Dump Clearance (bucket at 45 deg.) . . . . . . . . . 2.54 m (8 ft. 4 in.) 2.69 m (8 ft. 10 in.) 2.67 m (8 ft. 9 in.) 2.62 m (8 ft. 7 in.)
T Reach at Full Height (bucket at 45 deg.) . . . . . . 902 mm (35.5 in.) 762 mm (30.0 in.) 787 mm (31.0 in.) 818 mm (32.2 in.)
U Digging Depth Below Ground (bucket level) . . . . 107 mm (4.2 in.) 170 mm (6.7 in.) 157 mm (6.2 in.) 182 mm (7.2 in.)
V Length From Front Axle Centerline to
Bucket Cutting Edge . . . . . . . . . . . . . . . . . . . . . 2.18 m (7 ft. 2 in.) 2.03 m (6 ft. 8 in.) 2.03 m (6 ft. 8 in.) 2.15 m (7 ft. 1 in.)
Lift Capacity with Quick-Coupler / Forks
Hydraulic Capacity . . . . . . . . . . . . . . . . . . . . . . . . 1219-mm (48 in.) tines 1524-mm (60 in.) tines
A' maximum Height. . . . . . . . . . . . . . . . . . . . . . . . 2073 kg (4,570 lb.) 1891 kg (4,170 lb.)
B' maximum Reach . . . . . . . . . . . . . . . . . . . . . . . . 3162 kg (6,971 lb.) 3003 kg (6,621 lb.)
C' At Ground Line . . . . . . . . . . . . . . . . . . . . . . . . . 4145 kg (9,138 lb.) 3883 kg (8,561 lb.)
D' Below Ground Line . . . . . . . . . . . . . . . . . . . . . . 211 mm (8.3 in.) 211 mm (8.3 in.)
