Hydraulics
410J
main Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pressure-compensated load sensing (PCLS), axial piston
Pump Flow @ 2,200 rpm
Backhoe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159 L/m (42 gpm)
Loader. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159 L/m (42 gpm)
System Relief Pressure
Backhoe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 993 kPa (3,625 psi)
Loader. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 993 kPa (3,625 psi)
Backhoe Controls . . . . . . . . . . . . . . . . . . . . . . . . . two-lever manual standard; pilot controls with pattern select, three-lever manual controls with foot swing, and manual and/or electric
auxiliary functions optional
Loader Controls . . . . . . . . . . . . . . . . . . . . . . . . . . single-lever control with electric clutch cutoff switch standard; manual auxiliary function optional
Cylinders
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . heat-treated, chrome-plated, polished rods; hardened-steel (replaceable bushings) pivot pins
Bore
Rod Diameter
Stroke
Loader Boom (2) . . . . . . . . . . . . . . . . . . . . . . . . . 80 mm (3.15 in.)
50 mm (1.97 in.)
790 mm (31.10 in.)
Loader Bucket (1) . . . . . . . . . . . . . . . . . . . . . . . . 90 mm (3.54 in.)
50 mm (1.97 in.)
744 mm (29.29 in.)
Backhoe Boom (1) . . . . . . . . . . . . . . . . . . . . . . . . 125 mm (4.92 in.)
63 mm (2.48 in.)
897 mm (35.31 in.)
Backhoe Crowd (1) . . . . . . . . . . . . . . . . . . . . . . . 115 mm (4.53 in.)
63 mm (2.48 in.)
698 mm (27.49 in.)
Backhoe Bucket (1) . . . . . . . . . . . . . . . . . . . . . . . 100 mm (3.94 in.)
63 mm (2.48 in.)
810 mm (31.89 in.)
Backhoe Swing (2). . . . . . . . . . . . . . . . . . . . . . . . 90 mm (3.54 in.)
50 mm (1.97 in.)
278 mm (10.94 in.)
Backhoe Extendable Dipperstick (1) . . . . . . . . . 70 mm (2.76 in.)
40 mm (1.57 in.)
1214 mm (47.78 in.)
Backhoe Stabilizer, Standard (2) . . . . . . . . . . . . 100 mm (3.94 in.)
50 mm (1.97 in.)
500 mm (19.69 in.)
Non-Powered Axle (1) . . . . . . . . . . . . . . . . . . . . . 70 mm (2.76 in.)
42 mm (1.65 in.)
213 mm (8.39 in.)
Mechanical-Front-Wheel Drive (1) . . . . . . . . . . . 67 mm (2.64 in.)
42 mm (1.65 in.)
210 mm (8.27 in.)
Electrical
Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 volt
Alternator Rating . . . . . . . . . . . . . . . . . . . . . . . . . . 90 amp
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 halogen: 2 front and 2 rear (32,500 candlepower each); turn signals and flashers 2 front and 2 rear; stop and tailights and 2 rear reflectors
Operator Station
Type (SAE J1040) . . . . . . . . . . . . . . . . . . . . . . . . . canopy, isolation mounted, ROPS/FOPS, left/right access, with molded roof
Tires/Wheels
Front
Rear
Non-Powered Front Axle . . . . . . . . . . . . . . . . . . . . 11L-16 SL F-3 (12)
19.5L-24 R-4 (10)
14.5/75-16.1 SL F-3 (10) 21L-24 R-4 (10)
mechanical-Front-Wheel Drive . . . . . . . . . . . . . . . . 12.5/80-18 I-3 (10)
19.5L-24 R-4 (10)
340/80R18 XmCL
500/70R24 XmCL
12.5/80-18 I-3 (10)
21L-24 R-4 (10)
Serviceability
Hydraulic Oil Filter, Spin-On Enclosed Replace-
able Element, Vertically mounted . . . . . . . . . . 6-micron filtration / 1,000 service hours
Refill Capacities
Cooling System . . . . . . . . . . . . . . . . . . . . . . . . 25 L (26 qt.)
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 L (19 qt.)
Engine Oil (including vertical spin-on filter) . . . . 13 L (14 qt.)
Torque Converter and Transmission . . . . . . . . 15 L (16 qt.)
Fuel Tank (with ground-level fueling) . . . . . . . 155 L (41 gal.)
Hydraulic System . . . . . . . . . . . . . . . . . . . . . . 95 L (25 gal.)
Hydraulic Reservoir . . . . . . . . . . . . . . . . . . . . . 39 L (10.2 gal.)
mechanical-Front-Wheel-Drive Housing
Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.5 L (7 qt.)
Planetary (each) . . . . . . . . . . . . . . . . . . . . 1 L (1 qt.)
Operating Weights
With Full Fuel Tank, 79-kg (175 lb.) Operator,
and Standard Equipment . . . . . . . . . . . . . . . . . 6839 kg (15,080 lb.)
Typical with Cab, mechanical-Front-Wheel
Drive, Extendable Dipperstick, and
454-kg (1,000 lb.) Counterweight . . . . . . . . . . 8426 kg (18,580 lb.)
Optional Components
Cab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263 kg (580 lb.)
mechanical-Front-Wheel Drive with Tires . . . . 220 kg (485 lb.)
Extendable Dipperstick . . . . . . . . . . . . . . . . . . 289 kg (638 lb.)
Front Loader Coupler . . . . . . . . . . . . . . . . . . . . 286 kg (630 lb.)
Backhoe Bucket Coupler . . . . . . . . . . . . . . . . . 63 kg (138 lb.)
