John Deere J BACKHOES 310SJ TMC - Manual (Page 33)

Lift capacities are over-end values in kg (lb.) according to
SAE J31. Figures listed are 87% of the maximum lift force
available. Base vehicle includes counterweight.
A'
B'
C'
D'
SWING PIVOT SWING PIVOT
DIPPER
LIFT
WITH
BOOM
AT 60 °
0 4 8 12 16 20
0 1 2 3 4 5 6 7
FEET
METERS FEET
METERS
12
8
4
0
4
8
12
12
8
4
0
4
8
12
0 4 8 12 16 20 24
0 1 2 3 4 5 6 7 8
4
3
2
1
0
1
2
3
4
4
3
2
1
0
1
2
3
4
1344 (2,962)
1356 (2,989)
1340 (2,954)
1312 (2,893)
1280 (2,823)
1247 (2,750)
1216 (2,680)
1186 (2,614)
1160 (2,558)
1143 (2,519)
1135 (2,503)
1150 (2,536)
2210
(4,872)
2249 (4,959)
2470 (5,446)
924 (2,036)
943 (2,079)
947 (2,088)
945 (2,084)
939 (2,071)
931 (2,053)
914 (2,014)
921 (2,031)
906 (1,997)
902 (1,988)
902 (1,988)
912 (2,010)
935 (2,062)
1529 (3,371)
1541 (3,398)
1606 (3,541)
1742 (3,841)
2023 (4,459)
1565 (3,450)
BOOM
LIFT
DIPPER
LIFT
WITH
BOOM
AT 60 °
1247 (2,749)
2311 (5,094)
BOOM
LIFT
410J TMC Backhoe with 1.22-m (4 ft.)
Extendable Dipperstick, Retracted
410J TMC Backhoe with 1.22-m (4 ft.)
Extendable Dipperstick, Extended
Loader Dimensions / Performance 410J TMC
P Bucket Dump Angle (maximum) . . . . . . . . . . . . 45 deg.
Q Rollback Angle at Ground Level . . . . . . . . . . . . 40 deg.
Heavy-duty long lip Heavy-duty Heavy-duty Multipurpose
Bucket Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.96 m 3 (1.25 cu. yd.) 1.00 m 3 (1.31 cu. yd.) 1.15 m 3 (1.50 cu. yd.) 1.00 m 3 (1.31 cu. yd.)
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2184 mm (86 in.) 2337 mm (92 in.) 2388 mm (94 in.) 2337 mm (92 in.)
Standard Loader Option
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 405 kg (892 lb.) 521 kg (1,148 lb.) 548 kg (1,208 lb.) 817 kg (1,800 lb.)
Breakout Force . . . . . . . . . . . . . . . . . . . . . . . . . . . 45.4 kN (10,210 lb.) 45.8 kN (10,300 lb.) 45.2 kN (10,170 lb.) 42.9 kN (9,650 lb.)
Lift Capacity (full height) . . . . . . . . . . . . . . . . . . . . 3332 kg (7,340 lb.) 3269 kg (7,200 lb.) 3210 kg (7,070 lb.) 2996 kg (6,600 lb.)
R Height to Bucket Hinge Pin (maximum) . . . . . . . 3.35 m (11 ft. 0 in.) 3.35 m (11 ft. 0 in.) 3.35 m (11 ft. 0 in.) 3.35 m (11 ft. 0 in.)
S Dump Clearance (bucket at 45 deg.) . . . . . . . . . 2.54 m (8 ft. 4 in.) 2.69 m (8 ft. 10 in.) 2.67 m (8 ft. 9 in.) 2.62 m (8 ft. 7 in.)
T Reach at Full Height (bucket at 45 deg.) . . . . . . 902 mm (35.5 in.) 762 mm (30.0 in.) 787 mm (31.0 in.) 818 mm (32.2 in.)
U Digging Depth Below Ground (bucket level) . . . . 107 mm (4.2 in.) 170 mm (6.7 in.) 157 mm (6.2 in.) 182 mm (7.2 in.)
V Length From Front Axle Centerline to
Bucket Cutting Edge . . . . . . . . . . . . . . . . . . . . . 2.18 m (7 ft. 2 in.) 2.03 m (6 ft. 8 in.) 2.03 m (6 ft. 8 in.) 2.15 m (7 ft. 1 in.)
Tool-Carrier Loader Option
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 390 kg (860 lb.) 493 kg (1,085 lb.) 520 kg (1,145 lb.) 789 kg (1,737 lb.)
Breakout Force . . . . . . . . . . . . . . . . . . . . . . . . . . . 45.8 kN (10,300 lb.) 50.9 kN (11,450 lb.) 47.3 kN (10,640 lb.) 43.1 kN (9,680 lb.)
Lift Capacity (full height) . . . . . . . . . . . . . . . . . . . . 3008 kg (6,625 lb.) 3276 kg (7,215 lb.) 3094 kg (6,815 lb.) 2656 kg (5,850 lb.)
R Height to Bucket Hinge Pin (maximum) . . . . . . . 3.40 m (11 ft. 2 in.) 3.40 m (11 ft. 2 in.) 3.35 m (11 ft. 0 in.) 3.40 m (11 ft. 2 in.)
S Dump Clearance (bucket at 45 deg.) . . . . . . . . . 2.51 m (8 ft. 3 in.) 2.59 m (8 ft. 6 in.) 2.57 m (8 ft. 5 in.) 2.50 m (8 ft. 2 in.)
T Reach at Full Height (bucket at 45 deg.) . . . . . . 868 mm (34.2 in.) 762 mm (30.0 in.) 787 mm (31.0 in.) 836 mm (32.9 in.)
U Digging Depth Below Ground (bucket level) . . . . 122 mm (4.8 in.) 140 mm (5.5 in.) 140 mm (5.5 in.) 152 mm (6.0 in.)
V Length From Front Axle Centerline to
Bucket Cutting Edge . . . . . . . . . . . . . . . . . . . . . 2.30 m (7 ft. 7 in.) 2.15 m (7 ft. 1 in.) 2.15 m (7 ft. 1 in.) 2.27 m (7 ft. 5 in.)
Lift Capacity with Quick-Coupler / Forks
Hydraulic Capacity . . . . . . . . . . . . . . . . . . . . . . . . 1219-mm (48 in.) tines 1524-mm (60 in.) tines
A' maximum Height. . . . . . . . . . . . . . . . . . . . . . . . 2211 kg (4,875 lb.) 2053 kg (4,526 lb.)
B' maximum Reach . . . . . . . . . . . . . . . . . . . . . . . . 3438 kg (7,580 lb.) 3294 kg (7,261 lb.)
C' At Ground Line . . . . . . . . . . . . . . . . . . . . . . . . . 4400 kg (9,700 lb.) 4180 kg (9,215 lb.)
D' Below Ground Line . . . . . . . . . . . . . . . . . . . . . . 211 mm (8.3 in.) 211 mm (8.3 in.)
DKAJLBH Page 33
