26–27
Lift capacities are over-end values in kg (lb.) according to SAE J31.
Figures listed are 87% of the maximum lift force available.
Base vehicle includes counterweight.
A'
B'
C'
D'
SWING PIVOT SWING PIVOT
DIPPER
LIFT
WITH
BOOM
AT 65 °
BOOM
LIFT
0 4 8 12 16 20
0 1 2 3 4 5 6 7
FEET
METERS FEET
METERS
5
4
3
2
1
0
1
2
3
4
16
12
8
4
0
4
8
12
5
4
3
2
1
0
1
2
3
4
16
12
8
4
0
4
8
12
0 4 8 12 16 20
0 1 2 3 4 5 6 7
1415 (3,119)
1415 (3,119)
1383 (3,049)
1342 (2,958)
1298 (2,862)
1257 (2,771)
1217 (2,684)
1182 (2,606)
1150 (2,536)
1127 (2,484)
1117 (2,462)
1140 (2,514)
2259
(4,981)
2303 (5,078)
2591 (5,712)
1989 (4,384) 991 (2,184)
997 (2,197)
992 (2,188)
979 (2,158)
965 (2,127)
949 (2,092)
918 (2,023)
931 (2,053)
906 (1,997)
896 (1,975)
894 (1,971)
902 (1,988)
933 (2,058)
1335 (2,945)
1431 (3,155)
1530 (3,373)
1674 (3,691)
1991 (4,390)
1213 (2,674)
3780
(8,334)
BOOM
LIFT
DIPPER
LIFT
WITH
BOOM
AT 65 °
1500 (3,306)
310SJ TMC Backhoe with 1.07-m (3 ft. 6 in.)
Extendable Dipperstick, Retracted
310SJ TMC Backhoe with 1.07-m (3 ft. 6 in.)
Extendable Dipperstick, Extended
Loader Dimensions / Performance
(See page 25 for line art) 310SJ TMC
P Bucket Dump Angle (maximum) . . . . . . . . . . . . 45 deg.
Q Rollback Angle at Ground Level . . . . . . . . . . . . 40 deg.
Heavy-duty Heavy-duty Heavy-duty long lip Heavy-duty Multipurpose Multipurpose
Bucket Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.77 m 3 0.86 m 3 0.96 m 3 1.00 m 3 0.96 m 3 1.00 m 3
(1.00 cu. yd.) (1.12 cu. yd.) (1.25 cu. yd.) (1.31 cu. yd.) (1.25 cu. yd.) (1.31 cu. yd.)
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2184 mm (86 in.) 2184 mm (86 in.) 2184 mm (86 in.) 2337 mm (92 in.) 2184 mm (86 in.) 2337 mm (92 in.)
R Height to Bucket Hinge Pin (maximum) . . . . . . . 3.40 m (11 ft. 2 in.) 3.40 m (11 ft. 2 in.) 3.40 m (11 ft. 2 in.) 3.40 m (11 ft. 2 in.) 3.40 m (11 ft. 2 in.) 3.40 m (11 ft. 2 in.)
Standard Loader Option
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 363 kg (800 lb.) 390 kg (860 lb.) 405 kg (892 lb.) 521 kg (1,148 lb.) 795 kg (1,750 lb.) 817 kg (1,800 lb.)
Breakout Force . . . . . . . . . . . . . . . . . . . . . . . . . . . 49.6 kN (11,160 lb.) 49.2 kN (11,051 lb.) 45.4 kN (10,210 lb.) 45.8 kN (10,300 lb.) 43.1 kN (9,700 lb.) 42.9 kN (9,650 lb.)
Lift Capacity (full height) . . . . . . . . . . . . . . . . . . . . 3368 kg (7,419 lb.) 3338 kg (7,353 lb.) 3332 kg (7,340 lb.) 3269 kg (7,200 lb.) 3042 kg (6,700 lb.) 2996 kg (6,600 lb.)
S Dump Clearance (bucket at 45 deg.) . . . . . . . . . 2.69 m (8 ft. 10 in.) 2.69 m (8 ft. 10 in.) 2.48 m (8 ft. 2 in.) 2.64 m (8 ft. 8 in.) 2.62 m (8 ft. 7 in.) 2.62 m (8 ft. 7 in.)
T Reach at Full Height (bucket at 45 deg.) . . . . . . 785 mm (30.9 in.) 767 mm (30.2 in.) 911 mm (35.9 in.) 765 mm (30.1 in.) 818 mm (32.2 in.) 818 mm (32.2 in.)
U Digging Depth Below Ground (bucket level) . . . . 160 mm (6.3 in.) 175 mm (6.9 in.) 147 mm (5.8 in.) 206 mm (8.1 in.) 185 mm (7.3 in.) 185 mm (7.3 in.)
V Length From Front Axle Centerline to
Bucket Cutting Edge . . . . . . . . . . . . . . . . . . . . . 2.03 m (6 ft. 8 in.) 2.03 m (6 ft. 8 in.) 2.18 m (7 ft. 2 in.) 2.03 m (6 ft. 8 in.) 2.20 m (7 ft. 3 in.) 2.15 m (7 ft. 1 in.)
Tool-Carrier Loader Option
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 379 kg (835 lb.) 396 kg (873 lb.) 390 kg (860 lb.) 493 kg (1,085 lb.) 766 kg (1,687 lb.) 789 kg (1,737 lb.)
Breakout Force . . . . . . . . . . . . . . . . . . . . . . . . . . . 50.2 kN (11,287 lb.) 52.9 kN (11,900 lb.) 45.8 kN (10,300 lb.) 50.9 kN (11,450 lb.) 43.3 kN (9,740 lb.) 43.1 kN (9,680 lb.)
Lift Capacity (full height) . . . . . . . . . . . . . . . . . . . . 3190 kg (7,026 lb.) 3269 kg (7,200 lb.) 3008 kg (6,625 lb.) 3276 kg (7,215 lb.) 2701 kg (5,950 lb.) 2656 kg (5,850 lb.)
S Dump Clearance (bucket at 45 deg.) . . . . . . . . . 2.58 m (8 ft. 6 in.) 2.61 m (8 ft. 7 in.) 2.51 m (8 ft. 3 in.) 2.59 m (8 ft. 6 in.) 2.50 m (8 ft. 2 in.) 2.50 m (8 ft. 2 in.)
T Reach at Full Height (bucket at 45 deg.) . . . . . . 777 mm (30.6 in.) 744 mm (29.3 in.) 868 mm (34.2 in.) 762 mm (30.0 in.) 836 mm (32.9 in.) 836 mm (32.9 in.)
U Digging Depth Below Ground (bucket level) . . . . 140 mm (5.5 in.) 140 mm (5.5 in.) 122 mm (4.8 in.) 140 mm (5.5 in.) 152 mm (6.0 in.) 152 mm (6.0 in.)
V Length From Front Axle Centerline to
Bucket Cutting Edge . . . . . . . . . . . . . . . . . . . . . 2.15 m (7 ft. 1 in.) 2.15 m (7 ft. 1 in.) 2.30 m (7 ft. 7 in.) 2.15 m (7 ft. 1 in.) 2.32 m (7 ft. 7 in.) 2.27 m (7 ft. 5 in.)
Lift Capacity with Quick-Coupler / Forks
Hydraulic Capacity . . . . . . . . . . . . . . . . . . . . . . . . 1219-mm (48 in.) tines 1524-mm (60 in.) tines
A' maximum Height. . . . . . . . . . . . . . . . . . . . . . . . 2211 kg (4,875 lb.) 2053 kg (4,526 lb.)
B' maximum Reach . . . . . . . . . . . . . . . . . . . . . . . . 3438 kg (7,580 lb.) 3294 kg (7,261 lb.)
C' At Ground Line . . . . . . . . . . . . . . . . . . . . . . . . . 4400 kg (9,700 lb.) 4180 kg (9,215 lb.)
D' Below Ground Line . . . . . . . . . . . . . . . . . . . . . . 211 mm (8.3 in.) 211 mm (8.3 in.)
