John Deere J BACKHOES 310SJ TMC - Manual (Page 19)

Lift capacities are over-end values in kg (lb.) according to SAE J31. Figures listed are 87% of the maximum lift force available. Base vehicle includes counterweight.
A'
B'
C'
D'
310J Backhoe with Standard Dipperstick
SWING PIVOT SWING PIVOT
DIPPER
LIFT
WITH
BOOM
AT 65 °
BOOM
LIFT
SWING PIVOT
DIPPER
LIFT
WITH
BOOM
AT 65 °
BOOM
LIFT
0 4 8 12 16 20
0 1 2 3 4 5 6 7
FEET
METERS 0 4 8 12 16 20
0 1 2 3 4 5 6 7
FEET
METERS FEET
METERS
5
4
3
2
1
0
1
2
3
4
16
12
8
4
0
4
8
12
5
4
3
2
1
0
1
2
3
4
16
12
8
4
0
4
8
12
5
4
3
2
1
0
1
2
3
4
16
12
8
4
0
4
8
12
0 4 8 12 16 20
0 1 2 3 4 5 6 7
1300 (2,867)
1259 (2,775)
1207 (2,662)
1154 (2,545)
1103 (2,432)
1056 (2,327)
1010 (2,227)
969 (2,136)
933 (2,058)
900 (1,984)
876 (1,931)
868 (1,914)
1837 (4,050)
1845 (4,067)
2056 (4,533)
2013 (4,437) 892 (1,966)
878 (1,936)
858 (1,892)
836 (1,844)
813 (1,792)
789 (1,740)
750 (1,653)
770 (1,697)
732 (1,614)
716 (1,579)
706 (1,557)
703 (1,549)
714 (1,575)
1235 (2,723)
1235 (2,723)
1296 (2,858)
1441 (3,176)
1778 (3,919)
1289 (2,841)
1466 (3,232)
1417 (3,123)
1362 (3,002)
1304 (2,875)
1251 (2,758)
1200 (2,645)
1154 (2,545)
1113 (2,453)
1073 (2,366)
1040 (2,292)
1014 (2,236)
1008 (2,223)
2204 (4,859)
2253 (4,968)
2017 (4,446)
2005 (4,420)
3473 (7,656) 2960
(6,525)
BOOM
LIFT
DIPPER
LIFT
WITH
BOOM
AT 65 °
310J Backhoe with 1.07-m (3 ft. 6 in.)
Extendable Dipperstick, Retracted
310J Backhoe with 1.07-m (3 ft. 6 in.)
Extendable Dipperstick, Extended
For more detailed spec information and available options, log on to www.JohnDeere.com.
Loader Dimensions / Performance 310J
P Bucket Dump Angle (maximum) . . . . . . . . . . . . 45 deg.
Q Rollback Angle at Ground Level . . . . . . . . . . . . 40 deg.
Heavy-duty Heavy-duty Heavy-duty long lip Multipurpose Multipurpose
Bucket Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.77 m 3 (1.00 cu. yd.) 0.86 m 3 (1.12 cu. yd.) 0.96 m 3 (1.25 cu. yd.) 0.77 m 3 (1.00 cu. yd.) 0.96 m 3 (1.25 cu. yd.)
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2184 mm (86 in.) 2184 mm (86 in.) 2184 mm (86 in.) 2083 mm (82 in.) 2184 mm (86 in.)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 363 kg (800 lb.) 390 kg (860 lb.) 405 kg (892 lb.) 771 kg (1,699 lb.) 795 kg (1,750 lb.)
Breakout Force . . . . . . . . . . . . . . . . . . . . . . . . . . . 41.6 kN (9,350 lb.) 42.3 kN (9,500 lb.) 39.9 kN (8,975 lb.) 37.3 kN (8,375 lb.) 36.4 kN (8,175 lb.)
Lift Capacity (full height) . . . . . . . . . . . . . . . . . . . . 2996 kg (6,600 lb.) 3076 kg (6,775 lb.) 2849 kg (6,275 lb.) 2554 kg (5,625 lb.) 3757 kg (8,275 lb.)
R Height to Bucket Hinge Pin (maximum) . . . . . . . 3.38 m (11 ft. 1 in.) 3.38 m (11 ft. 1 in.) 3.38 m (11 ft. 1 in.) 3.38 m (11 ft. 1 in.) 3.38 m (11 ft. 1 in.)
S Dump Clearance (bucket at 45 deg.) . . . . . . . . . 2.69 m (8 ft. 10 in.) 2.69 m (8 ft. 10 in.) 2.48 m (8 ft. 2 in.) 2.59 m (8 ft. 6 in.) 2.59 m (8 ft. 6 in.)
T Reach at Full Height (bucket at 45 deg.) . . . . . . 785 mm (30.9 in.) 767 mm (30.2 in.) 809 mm (31.9 in.) 818 mm (32.2 in.) 818 mm (32.2 in.)
U Digging Depth Below Ground (bucket level) . . . . 160 mm (6.3 in.) 175 mm (6.9 in.) 147 mm (5.8 in.) 197 mm (7.8 in.) 197 mm (7.8 in.)
V Length From Front Axle Centerline to
Bucket Cutting Edge . . . . . . . . . . . . . . . . . . . . . 2.03 m (6 ft. 8 in.) 2.03 m (6 ft. 8 in.) 2.18 m (7 ft. 2 in.) 2.15 m (7 ft. 1 in.) 2.20 m (7 ft. 3 in.)
Lift Capacity with Quick-Coupler / Forks
Hydraulic Capacity . . . . . . . . . . . . . . . . . . . . . . . . 1219-mm (48 in.) tines 1524-mm (60 in.) tines
A' maximum Height. . . . . . . . . . . . . . . . . . . . . . . . 1746 kg (3,850 lb.) 1556 kg (3,430 lb.)
B' maximum Reach . . . . . . . . . . . . . . . . . . . . . . . . 2688 kg (5,925 lb.) 2467 kg (5,438 lb.)
C' At Ground Line . . . . . . . . . . . . . . . . . . . . . . . . . 3493 kg (7,700 lb.) 3269 kg (7,207 lb.)
D' Below Ground Line . . . . . . . . . . . . . . . . . . . . . . 262 mm (10.3 in.) 262 mm (10.3 in.)
