Page 14

12
NETWORK SETUP menu screen
ⅷ
indicates default factory setting.
✩
indicates items that can also be set from the W
eb.
Item
HOST NAME
DHCP
IP ADDRESS
SUBNET MASK
GA
TE W
A
Y
NAME SER
VER
FTP Client
MACHINE
NAME
USER NAME
P
ASSWORD
DIRECT
OR
Y
P
ASSIVE
MODE
P
AGE BACK
P
AGE BACK
Setting
ⅷ
OFF
ON
ⅷ
OFF
ON
Men
u settings
NETW
ORK Settings men
u screen item
Description
Displays the host name input setting screen. (4 ~ 64 alphanumerical characters)
[Factory setting: none]
Select whether DHCP server is used.
OFF:
Use this setting when using LAN connection rather than DHCP
.
When this setting is used, IP
ADDRESS and SUBNET
MASK, GA
TEW
A
Y
must also be set.
ON:
Use this setting when using DHCP connection.
When using this setting, IP
ADDRESS and
SUBNET
MASK
, GA
TEW
A
Y
are automatically set.
*
When DHCP is set to ON,
WLAN ADHOC MODE cannot be set to AHDM or IBSS.
Displays the IP address setting screen.
When using LAN connection with DHCP
set to OFF
, this setting is required. Set a unique IP
address.
IP
ADDRESS setting is not available when DHCP
is set to ON.
[Factory setting] 192.168.100.101]
Displays the subnet mask input screen.
This setting is required when using LAN connection with DHCP
set to OFF
.
SUBNET MASK
setting is not available if DHCP is set to ON.
[Factory setting: 255.255.255.000]
Displays the gateway address input screen.
GA
TEW
A
Y
setting is not available when DHCP
is set to ON.
[Factory setting: 192.168.100.254]
Sets the address of the domain name server
. [Factory setting: 0.0.0.0]
Displays the FTP client setting screen.
Displays the host name/IP
address input screen of the FTP
server
. (Max.64 alphanumerical characters)
[Factory setting: none]
Displays the user name input setting screen for logging onto an FTP
server
. (Max.16 alphanumerical
characters)
In the case of “anonymous”, user name will be inputted automatically
. [Factory setting: anonymous]
Displays the password input setting screen for logging onto an FTP
server
. (Max.8 alphanumerical
characters)
Displays save folder input setting screen of the FTP
server
. [Factory setting:/home/none]
Selects ON/OFF of the P
ASSIVE mode.
If data connection cannot be established with the P
ASSIVE mode set to OFF
, set the P
ASSIVE
mode to ON.
Pressing the SET button or SEARCH– button returns the unit to the NETWORK SETUP screen.
Pressing the SET button or SEARCH– button returns the unit to the NETWORK MAIN SETUP
screen.
→
O
VER
✩
✩
✩
✩
✩
✩
✩
✩
✩
✩
✩
13
POR
T
SETUP
menu screen
ⅷ
indicates default factory setting.
Item
HTTP
for WEB
Browser
HTTP
for
Media player
R
TSP
for
Streamproducer
R
TSP
for Quick
Time
P
AGE BACK
Setting
1
:
ⅷ
80
:
32767
1
:
ⅷ
8080
:
32767
1
:
ⅷ
8554
:
32767
1
:
ⅷ
554
:
32767
Description
The screen for setting R
TSP
and HTTP
port numbers appears.
HTTP
for W
eb Browser can be set with the W
eb browser HTTP
port number and HTTP
for Media
Player can be set with the Media Player HTTP
port number
. R
TSP
for Streamproducer can be set
with the Streamproducer R
TSP
port number and R
TSP
for Quick
T
ime can be set with the Quick
T
ime R
TSP
port number
.
Normally
, the unit can be used without changing the factory settings.
If there are port restrictions for the LAN environment of your PC, consult your network administrator
.
*
When c
hanging a por
t n
umber
, ref
er to
“5-1.
Connecting with Camcor
der”
of the
“Streampr
oducer”
User’
s
Guide of the netw
ork distrib
ution software to c
hang
e por
t set-
tings.
* Do not use the same por
t number
s f
or R
TSP and HTTP
.
*
When a por
t n
umber is c
hanged,
s
witc
h the po
wer of the BR-D
V6000 off once
, and then
s
witc
h it on a
gain.
Pressing the SET button or SEARCH– button returns to the NETWORK SETUP menu screen.
Men
u settings
NETW
ORK Settings men
u screen item
WIRELESS LAN SETUP
menu screen
Item
AD HOC MODE
Primary ESS ID
Secondary ESS ID
Country
CH
WEP KEY
LEAP
P
AGE BACK
Setting
ⅷ
OFF
AHDM
IBSS
NONE
NONE
ⅷ
USA
EU
FRN
SPN
JPN
1CH
:
ⅷ
10CH
:
14CH
ON
ⅷ
OFF
Description
Wireless LAN setting
OFF:
Use this setting when performing communication via access point.
AHDM/IBSS:
Use this setting when performing communication in
AD HOC mode with a PC con-
nected with a wireless LAN card. (
☞
page 16)
*
When this item is set to AHDM or IBSS, DHCP cannot be set to ON.
Displays the wireless LAN ESS-ID input setting screen (Max. 32 alphanumerical characters)
Setting for the country using wireless LAN
USA: USA, EU: Europe, FRN: France
SPN: Spain, JPN: Japan
(Set according to operating environment.)
Wireless LAN channel setting
CH setting changes depending on the Country setting.
USA: 1 ~ 11CH, EU: 1 ~ 13CH, FRN: 10 ~ 13CH, SPN: 10, 11CH, JPN: 1 ~ 14CH
When encrypting data, set the WEP
KEY
(10 or 26 characters consisting or letters a ~ f and num-
bers). Must be compatible with access point authentication for the use of this item.
Set to ON when connecting a Cisco Systems wireless LAN device and using the LEAP
function.
Pressing the SET button or SEARCH– button
returns to the NETWORK MAIN SETUP menu screen.
Memo
The LEAP
function is exclusive to Cisco Systems wireless LAN devices. For details concerning
the LEAP
function, see the instruction manual accompanying the wireless LAN device.
→
