Operations
Image files can be transferred from CF card in DM-NC40 to PC by FTP. Use FTP client installed PC.
1.
From the command prompt of PC, type “ftp” to login. Default settings of
DM-NC40, 10.0.0.1 as IP address, OPERATOR as user, and dm-nc40 as
password, are used in following steps.
2.
Type “ls” to list image files or directories
Each directory contains 2 directories.
Jpeg-1: Image file directory of VIDEO IN1
Jpeg-2: Image file directory of VIDEO IN2
Each image file is saved using the file name shown below in jpeg-1 or jpeg-2 directories.
YY: last 2 digits of year, MM: month (01 ~ 12), DD: date (1 ~ 31), HH: hour (00 ~ 23), mm: minute (00 ~ 59), ss:
second (00 ~ 59), **: running number within the second value (00, 01, 02)
However, running numbers at the second of the start are 70, 71 and 72 to show the beginning. Running numbers at
the second of the end are 80-, 81 and 82 to show the last. Running numbers at the second of alarm input or manual
start are 90, 91 and 92 to show the timing.
Example: Recorded files at 12:34:56 on April 1, 2003
File names will be: 03040112345600.jpg
:
Operating of FTP
1 Enter “10.0.0.1” (IP address of the unit) after
“ftp” and press the Enter key.
3 Enter “dm-nc40” for Password and press
the Enter key. (Password will not be
displayed)
2 Enter “OPERATOR” for User and press the
Enter key.
4 Enter “ls” and press the Enter key.
5 Directories at root directory are shown.
(“manual” is directory including image files
recorded by panel operation)
If there is another alarm during previous recording, 3
files with running numbers 90 ~ 92 are recorded to show
the alarm timing.
(Example)
