29

Preparations

1.

Click Mode Setup in the Network Codec screen

The MODE SETUP screen is displayed.

5-1 Setting in the MODE SETUP screen

(Be sure to perform)

Step 5

Mode Setup

Select mode of the unit according to the system of use.

2 Click “Initialize to Preset Values”

to reset to the initial values of the
mode selected in

1

.

4 Click “Save User Mode” to

register the current settings as
the user mode.

3 Click “Delete User Mode” to

delete the user mode.

Select the mode according to the system of use.

Mode

System of use

Camera

Camera side of remote monitoring system (

see page 14)

Monitor

Monitoring side of remote monitoring system (

see page 14)

Teleconference

Teleconference system (

see page 13)

ISMA Server

Streaming system (

see page 15)

User Mode

Values changed in “Step 6 Detailed Setup” are saved.

Name of the mode will be “User_Mode_Camera”, etc. It means user defined mode

changed from Camera mode.

Click “Detailed Setup” to display
submenus.

Memo

When clicking this button, the
HOLD display lamp will turn on and
panel operations will be locked.

* The following screen appears on the Browser after performing changes, and the number display of the unit

will show a circling display.

and

are displayed

1

Select the mode.
(Factor y setting: CAMERA
mode)

Cautions concerning setting changes

Settings can not be changed when the unit is communicating with other units. Warning page is displayed on
Web browser if you try to chang settings during communication.

In such case, stop all communications with other units.

To check current communications, refer to “Telnet Settings” on page 54 and execute the “stat” command.

Memo

When the mode is changed, the unit will restart and all settings will return to their initial values of each mode.

If the current mode is “User Mode”, “User Mode” can not be deleted even when clicking “Delete User
Mode”. Do not click “Delete User Mode” during “User Mode”.

Only one “User Mode” can be saved.
