V.35 DTE Cable Pinout
Table 78: V.35 DTE Cable Pinout
Description LFH-60 Pairing M/34 Pin LFH-60 Pin
Frame Ground – A 15
Signal Ground – B 57
Request to Send – C 48
Clear to Send – D 37
Data Set Ready – E 9
Received Line Signal Detector – F 13
Data Terminal Ready – H 33
Test Mode – K 41
Transmit Data (A) 59 P 60
Receive Data (A) 2 R 1
Transmit Data (B) 60 S 59
Receive Data (B) 1 T 2
Terminal Timing (A) 51 U 52
Receive Timing (A) 6 V 5
Terminal Timing (B) 52 W 51
Receive Timing (B) 5 X 6
Transmit Timing (A) 55 Y 56
Transmit Timing (B) 56 AA 55
– – – 22 to 21
– – – 26 to 25
– – – 18 to 17
