Table 72: RS-232 DTE Cable Pinout (continued)
Description LFH-60 Pairing DB-25 Pin LFH-60 Pin
– – – 18 to 17
RS-232 DCE Cable Pinout
Table 73: RS-232 DCE Cable Pinout
Description LFH-60 Pairing DB-25 Pin LFH-60 Pin
Frame Ground – 1 15
Transmit Data – 2 1
Receive Data – 3 60
Request to Send – 4 37
Clear to Send – 5 48
Data Set Ready – 6 33
Signal Ground – 7 57
Data Carrier Detect – 8 13
Transmit Clock – 15 56
Receive Clock – 17 52
Local Loopback – 18 45
Data Terminal Ready – 20 9
Terminal Clock – 24 5
– – – 22 to 21
RS-422/449 (EIA-449) DTE Cable Pinout
Table 74: RS-422/449 (EIA-449) DTE Cable Pinout
Description LFH-60 Pairing DC-37 (DB-37) Pin LFH-60 Pin
Shield Ground – 1 15
Send Data (A) 59 4 60
Send Timing (A) 55 5 56
