35 Previous
screen
The projection mode used by the projector can be changed in
accordance with the setting-up position. You may select from
two direction types. At the time of shipment from the factory,
the projector is set to the “Front” projection mode, but this can
be changed if required.
The procedure and on-screen display as shown below are
based on RGB as the input signal from a personal computer.
• Selecting procedure
1
Press MENU to
display the menu.
2
Press or to
select “Function”,
and then ENTER to
display the screen.
3
Press or to
select “Projection
Mode”.
4
Press or to
select projecting
mode.
• Front (Factory
setting)
• Rear (Right and
Left displays in
reverse)
White Balance
Synchronization
Function
Language
Information
RGB/YP
B
P
R
Projection Mode
Expansion
On Screen Display
Auto Lamp Off
Standard (Push ENTER)
•RGB •YP
B
P
R
•Front •Rear
•ON •OFF
•ON •OFF
•YES •NO
Function
Changing the Projection Mode
