• Because each Y, P
B
, and P
R
signal is input independently, the
Component signal allows for more faithful color reproduction.
• The Component signal output terminal indication will differ
according to the output device (P
R
, P
B
, Y/R-Y, B-Y, Y/Cr, Cb, Y,
etc.). Please read the operating instructions included with the
output device.
• You need to change the input signal setting on this LCD
Projector when inputting the Component signal. In this case,
please refer to “
Setting of the RGB/YP
B
P
R
Input Signal
Selection ”.
• D-sub15-BNC5 (female) Adaptor Cable (sold separately) often
have BNC connectors, however a DVD output device usually
has RCA jacks. In this case, you will need BNC-RCA adaptors
(not included).
Note
System Configuration Example
Notes on system configuration
• Turn off the power supply of each system component before
connecting any of the components.
• Read the instruction manual for each system component before
connecting it.
• If the cables necessary for connecting a component to the
system are not included with the component or available as an
option, you may need to fashion a cable to suit the component
concerned.
• If there is a lot of jitter in the video signal input from the video
source, the picture on the screen may flicker. In such cases, it
will be necessary to connect a TBC (time base corrector).
• It may not be possible to connect some types of personal
computer.
