- 91 -
Item Part No. Description Qty.
REMARK:
Item Part No. Description Qty.
5.12 Hydraulic Schematic
1 38522 Transmission Pump 1
2 38518 Pump Steering Eccentric 1
3 38523 Flow Divider Combiner 33/67 1
4 38520 Filter Hydraulic 1
38638 Element Filer 1
5 38524 Control Steering 1
6 38521 Breather Filler 1
7 46362 Cylinder Steering 2.5 x 10 1
8 38528 Wheelmotor Rear 1
9 38527 Wheelmotor Front with Brake 2
10 38529 Valve Priority Steering 1
11 38531 Motor Eccentric 1
12 35482 Strainer 25GPM 1
13 38727 Manifold Eccentrics 1
14 38526 Valve Blade 1
15 46444 Cylinder Blade 2 x 8 2
16 38663 Flow Divider Combiner 50/50 1
17 38689 Valve Brake 1
18 38446 Cooler Oil 1
