- 79 -
Item Part No. Description Qty.
REMARK:
Item Part No. Description Qty. FT. LBS. (Nm)
Torque
5.8 Controls
1 36268 Hour Meter 1
2 39609 Volt Meter 1
3 39610 Gauge Oil Pressure 1
39598 Sendor Oil Pressure 1
4 39611 Gauge Coolant Temperature 1
39599 Sendor Coolant Temperature 1
5 39612 Push Button 1
6 39607 Key Switch 1
39637 Key Ignition 1
7 38711 Fuse Holder 1
8 36311 Fuse 20A 1
9 39653 Switch Rocker On/Off 1
10 39584 Cable Throttle 1
11 47314 Cover Dust 2
12 47315 Gasket Cover Dust 2
13 39608 Relay Starter 1
14 38662 Clamp Cable ½ 2
15 38800 Clamp Conduit ½ 2
16 38602 Cable Forward/Reverse 1
38602 Cable Forward/Reverse (Blade Unit) 2
17 38559 Backup Alarm 112 dBA 1
18 38667 Horn 12V 125 dBA 1
19 41007 Clamp Cable 1
20 42076 Lever Cable 1
A* 80434 HHCS 1/4 - 20 X 3/4 GR ZN 2 6 (8)
HHCS 1/4 - 20 X 3/4 GR ZN (Blade Unit) 4 6 (8)
B 80518 NUTFL 1/4 - 20 ZN 3 - -
NUTFL 1/4 - 20 ZN (Blade Unit) 6 - -
C 80347 WSHR 1/4 WROT ZN 16 - -
D* 80788 WSHR SPRING 1/4 ID (Blade Unit) 6 - -
E* 80791 PPHMS 1/4 - 20 X 3/4 BLK 4 - -
F 80448 PINCT 1/16 X 1/2 1 - -
G 80442 SHCS #10 - 32 X 1/2 BLK 1 - -
H* 80481 HHCS 5/16 - 18 X 1 GR5 ZN 2 13 (18)
I 80086 WSHRL 5/16 SPLIT ZN 4 - -
J 80348 WSHR 5/16 WROT ZN 8 - -
K 80686 HHCS 3/8 - 16 X 3/4 GR8 ZN 2 23 (31)
M 80346 WSHR #10 SAE ZN 20 - -
N 80693 NUTNY 10 - 24 ZN 11 - -
O 80085 HWHTB 5/16 - 18 X 1 ZN 4 13 (18)
P 80114 NUTNY 5/16 - 18 ZN 2 - -
Q 80056 NUTNY 3/8 - 16 ZN 2 - -
R 80527 PPHMS 10 - 24 X 5/8 ZN 6 - -
S* 80161 HHCS 5/16 - 18 X 1 ZN 1 13 (18)
T* 80157 HHCS 1/4 - 20 X 1 - 1/2 ZN - 6 (8)
V* 80354 HHCS 1/4 - 20 X 1 2 6 (8)
80709 HHCS 1/4 - 20 X 2 GR8 ZN (Blade Unit) 2 6 (8)
X 80153 HWHST 1/4 - 20 X 3/4 ZN 12 6 (8)
Y 80449 SHCS 10 - 24 X 5/8 BLK 2 - -
* Loctite Required
