- 73 -
Item Part No. Description Qty.
REMARK:
Item Part No. Description Qty. FT. LBS. (Nm)
Torque
5.6 Engine
1 30558 Engine Deere 3029 1
2 39577 Fan Nylon 1
3 39578 Spacer Fan 1
4 43799 Mount Relay 1
5 48401 Relay 70A 1
6 43782 Muffler 1
7 39621 Gasket 1
8 39620 Half Clamp 2
9 43715-2 Mount Weld LH Engine 1
10 43714-2 Mount Weld RH Engine 1
11 43254-2 Bracket Inner Bell Housing 1
12 39636 Drive Plate and Cover 1
13 39595 Plate Throttle 1
14 39596 Bracket Throttle 1
15 39597 Spacer Throttle 2
16 43749-2 Support Exhaust 1
17 43746-2 Exhaust Pipe 1
18 39585 Clamp Muffler 2-1/4 2
Fuel Lines (not shown)
- 46813 Hose Return ¼ ID 25”
- 39593 Fitting Return Engine 1
- 46127 Fitting Return Tank 1
- 46814 Hose Supply 5/16 ID 36”
- 46815 Fitting Supply Tank 1
- 34089 Clamp Hose 5/8 4
A
*
80170 HHCS 5/16-18 X 2-1/2 GR5 ZN 4 13 (18)
B 80086 WSHRL 5/16 SPLIT ZN 6 - -
C 80527 PPHMS 10-24 X 5/8 ZN 1 - -
D 80346 WSHR #10 SAE ZN 1 - -
E 80693 NUTNY 10-24 ZN 1 - -
F
*
80113 HHCS ½-13 X ¾ GR5 ZN 1 57 (77)
G 80117 WSHRL ½ SPLIT ZN 9 - -
H
*
80178 HHCS 3/8-16 X 2 GR5 ZN 1 23 31)
I 80342 WSHR 3/8 SAE ZN 2 - -
J 80325 NUTFL 3/8-16 REG ZN 1 - -
K
*
80163 HHCS 5/16-18 X 1-1/2 GR5 ZN 2 - -
L
*
80703 HHCS ½-13 X 1-1/2 GR5 ZN 8 - -
M 80343 WSHR ½ SAE ZN 8 - -
N
*
80204 HHCS 5/8-11 X 1-1/2 GR5 ZN 4 112 (152)
O 80355 WSHR 5/8 SAE ZN 4 - -
P 80337 WSHRL 5/8 SPLIT ZN 4 - -
Q 80058 WSHRL 3/8 SPLIT ZN 8 - -
R
*
80686 HHCS 3/8-16 X ¾ GR8 ZN 20 23 (31)
S
*
80716 HHCS 3/8-16 X 1-1/4 GR8 ZN 12 23 (31)
T
*
80942 HHCS 3/8-16 X 5 GR5 ZN 2 23 (31)
U 80567 HWHTB ¼-20 X 3/8 ZN 2 6 (8)
V 80676 NUTNY ¼-20 ZN 2 - -
* Loctite Required
