5.5 Radiator and Engine Mount
1 43255-2 Bracket Outer Bell Housing 1
2 47281 Shock Mounts 6
3 43715-2 Mount Weld LH Engine 1
4 43714-2 Mount Weld RH Engine 1
5 42129-2 Bracket S-MTG Engine 2
6 39576 Guard Fan 1
7 39574 Radiator 1
39606 Cap Radiator 1
39602 Hose Radiator Upper 1
39603 Hose Radiator Lower 1
39600 Clamp Hose 2" 2
39601 Clamp Hose 2-1/4" 2
39604 Petcock Radiator 1
8 43245-2 Mount Weld Radiator RH 1
9 43246-2 Mount Weld Radiator LH 1
10 39575 Shroud Radiator 1
11 43249-2 Plate Mount Cooler 2
12 43805-2 Radiator Support 1
13 38627 Rubber Mount Cooler 4
14 42460-2 Bracket Cowl Stop 1
15 38815 Stop Cable 1
A* 80161 HHCS 5/16 - 18 X 1 GR 5 ZN 4 13 (18)
B* 80658 HHCS 1/2 - 20 X 1 GR5 ZN 6 57 (77)
C 80058 WSHRL 3/8 Split ZN 6 - -
D 80041 CRBLT 3/8 - 16 X 1 - 1/4 ZN 3 - -
E 80043 WSHR 3/8 WROT ZN 15 - -
F 80564 WSHR 3/8 ID X 1/4 OD ZN 4 - -
G 80056 NUTNY 3/8 - 16 ZN 11 23 (31)
H 80114 NUTNY 5/16 - 18 ZN 4 13 (18)
I 80537 NUTFL 1/2 - 20 ZN 6 64 (87)
J 80343 WSHR 1/2 SAE ZN PL 20 - -
K 80117 WSHRL 1/2 MED SPLIT ZN 6 - -
L 80682 CRBLT 5/16 - 18 X 2 - 1/2 ZN 4 - -
M 80086 WSHRL 5/16 MED SPLIT ZN 4 - -
N 80355 WSHR 5/8 SAE ZN 4 - -
O 80082 NUTNY 5/8 - 11 ZN 2 112 (152)
P* 80695 HHCS 5/8 - 11 X 2 GR5 ZN 2 112 (152)
Q 80347 WSHR ¼ WROT ZN 4 - -
R 80116 WSHRL ¼ SPLIT ZN 4 - -
S* 80174 HHCS 3/8 - 16 X 1 GR5 ZN 6 23 (31)
T*80561 HHCS 1/2 - 13 X 1 - 3/4 GR5 ZN 4 57 (77)
U 80051 NUTNY 1/2 - 13 ZN 4 57 (77)
V 80348 WSHR 5/16 WROT ZN 2 - -
W* 80434 HHCS 1/4-20 x 3/4 GR5 ZN 4 6 (8)
X * 80474 HHCS 3/8-16 x 1-1/4 GR5 ZN 4 - -
* Loctite Required
