4 main frame cont'd – John Deere rhino pd54 User Manual
Page 69
- 69 -
Item
Part No.
Description
Qty.
FT. LBS. (Nm)
REMARK:
Item
Part No.
Description
Qty.
FT. LBS. (Nm)
Torque
Torque
32
38600
Seat Belt
1
33
43251-2
Tank Hydraulic
1
34
29700-2
ROPS
1
35
29702-2
ROPS Support
1
36
42215-2
Bracket Hose
2
37
42216-2
Bracket Hose
1
38
42075-2
Panel Front
1
39
42222-2
Panel Rear
1
40
46450
Steering Wheel
1
41
46452
Column
1
42
46449
Horn Kit
1
43
47217
Nut Steering
1
44
47247
Grommet Rubber 2" ID
1
A
80041
CRBLT 3/8 - 16 X 1 - 1/4 ZN
4
-
-
B
80043
WSHR 3/8 WROT ZN
6
-
-
C
80056
NUTNY 3/8 - 16 ZN
6
23
(31)
D
80610
HWHTB 3/8 - 16 X 1 - 1/4 ZN
8
23
(31)
E
80085
HWHTB 5/16 - 18 X 1 ZN
22
13
(18)
F
80082
NUTNY 5/8 - 11 ZN
12
112
(152)
G
80355
WSHR 5/8 SAE ZN
24
-
-
H*
80695
HHCS 5/8 - 11 X 2 GR5 ZN
12
112
(152)
I*
80561
HHCS 1/2 - 13 X 1 - 3/4 GR5 ZN
12
57
(77)
* Loctite Required
5.4 Main Frame Cont'd.
J*
80476
HHCS 3/8 - 16 X 1 - 1/2 ZN
4
23
(31)
K
80058
WSHRL 3/8 SPLIT ZN
4
-
-
L*
80668
HHCS 3/4 - 10 X 2 GR8 BLK
2
282
(382)
M*
80669
HHCS 3/4 - 10 X 2 - 1/2 GR8 ZN
4
282
(382)
N*
80684
HHCS 1 - 8 X 3 GR8 BLK
4
682
(925)
O
80685
WSHRL 1 SPLIT ZN
4
-
-
P
80670
NUTFX 3/4 - 10 BLK
4
-
-
Q
80671
WSHRL 3/4 SPLIT ZN
6
-
-
R
80346
WSHR #10 SAE ZN
6
-
-
S
80693
NUTNY 10 - 24 ZN
4
-
-
T
80696
FHSMS 10 - 24 X 1 ZN
2
-
-
V
80527
PPHMS 10 - 24 X 5/8 ZN
4
-
-
W
80348
WSHR 5/16 WROT ZN
8
-
-
X
80114
NUTNY 5/16 - 18 ZN
10
13
(18)
Y
80051
NUTNY 1/2 - 13 ZN
12
-
-
Z
80343
WSHR 1/2 SAE ZN
24
-
-
AA
80587
CRBLT 3/8 - 16 X 1 ZN
2
-
-
BB*
80257
RHSMS 10 - 24 X 3/8 BLK
2
-
-
CC*
41038
LUG NUT M14 x 60
°
10
184
(250)
