3 drum assembly cont'd – John Deere rhino pd54 User Manual
Page 65
- 65 -
Item
Part No.
Description
Qty.
FT. LBS. (Nm)
REMARK:
Item
Part No.
Description
Qty.
FT. LBS. (Nm)
Torque
Torque
37
47301
O-Ring 3 - 1/4 ID X 1/16 CS
1
38
32251
Seal V-RING 6" DIA.
1
39
22770
Kit Brake Release
1
40
42345
Scraper POLY SD43
2
42346
Scraper POLY SD54
2
41
42493-2
Bar Mount PIVOT
4
A#*
80561
HHCS 1/2 - 13 X 1-3/4 GR5 ZN
24
57
(77)
##*
80561
HHCS 1/2 - 13 X 1-3/4 GR5 ZN
76
57
(77)
B#*
80085
HWHST 5/16 - 18 X 1 ZN
4
13
(18)
##*
80085
HWHST 5/16 - 18 X 1 ZN
13
13
(18)
C#
80117
WSHRL 1/2 MED SPLIT ZN
43
-
-
##
80117
WSHRL 1/2 MED SPLIT ZN
44
-
-
###
80117
WSHRL 1/2 MED SPLIT ZN
47
-
-
D*
80680
SHCS 1/2 - 13 X 2 - 1/2 ZN
5
57
(77)
E
80086
WSHRL 5/16 MED SPLIT ZN
3
-
-
F*
80049
SHCS 5/16 - 18 X 1 - 1/4 BLK
3
13
(18)
G#*
80537
NUTFL 1/2 - 20 ZN
10
64
(87)
##
80537
NUTFL 1/2 - 20 ZN
12
64
(87)
###
80537
NUTFL 1/2 - 20 ZN
14
64
(87)
H
80125
WSHR 17/32 ID X 1 - 1/16 ZN
16
-
-
I#*
80658
HHCS 1/2 - 20 X 1 GR5 ZN
5
64
(87)
##*
80658
HHCS 1/2 - 20 X 1 GR5 ZN
6
64
(87)
###*
80658
HHCS 1/2 - 20 X 1 GR5 ZN
7
64
(87)
J#*
80678
HHCS 1/2 - 20 X 3 GR5 ZN
5
64
(87)
##*
80678
HHCS 1/2 - 20 X 3 GR5 ZN
6
64
(87)
###*
80678
HHCS 1/2 - 20 X 3 GR5 ZN
7
64
(87)
K*80474
HHCS 3/8 - 16 X 1 - 1/4 GR 5 ZN
2
23
(31)
M
80043
WSHR 3/8 WROTZN
14
-
-
N
80056
NUTNY 3/8 - 16 ZN
7
23
(31)
O
80058
WSHRL 3/8 MRD SPLIT ZN
2
-
P*
80643
HHCS 3/8 - 16 X 7 GR5 ZN
1
23
(31)
Q*
80405
HHCS 1/2 - 13 X 2 - 3/4 GR5 ZN
12
57
(77)
R*
80681
SHCS 5/8 - 11 X 1 - 1/2 BLK
8
190
(257)
S
80337
WSHRL 5/8 MED SPLIT ZN
18
-
-
T*
80695
HHCS 5/8 - 11 X 2 GR5 ZN
18
112
(152)
V
80355
WSHR 5/8 SAE ZN
40
-
-
W
80082
NUTNY 5/8 - 11 ZN
14
112
(152)
X
80051
NUTNY 1/2 - 13 ZN
16
57
(77)
Y*
80699
HHCS 5/8 - 11 X 3 - 1/4 GR5 ZN
8
112
(152)
Z*
80113
HHCS 1/2 - 13 X 3/4 ZN
6
57
(77)
AA#
80343
WSHR 1/2 SAE ZN
64
-
-
##
80343
WSHR 1/2 SAE ZN
68
-
-
###
80343
WSHR 1/2 SAE ZN
72
-
-
BB*
80694
HHCS 3/8 - 13 X 4 - 1/2 GR5 ZN
4
-
-
CC*
80578
HHCS 1/2 - 13 X 3 GR5 ZN
4
57
(77)
DD
80641
HHTB M12 X 100MM GR8.8 ZN
1
-
-
EE
80700
NUTFX M12 ZN
1
-
-
FF
26326
WSHR 9/16 X 1 - 3/4 X 1/4
1
-
-
5.3 Drum Assembly Cont'd.
# SD43, PD43 ## SD54, PD54, PDB43 ### PDB54
*Loctite Required
