- 87 -
Item Part No. Description Qty.
REMARK:
Item Part No. Description Qty. FT. LBS. (Nm)
Torque
5.10 Steering / Eccentric System Hydraulics
1 38524 CONTROL STEERING 1
2 46362 CYLINDER TIE ROD 2.5 X 10 1
44203 PIN CLEVIS 1" 2
44204 RUE RING 1" 2
3 38529 PRIORITY VALVE 1
4 38727 MANIFOLD MODULAR 1
5 46533 HOSE HYD 7/8 FJ X 7/8 FJ 73 1
6 38446 COOLER HYD OIL 1
7 46404 FTG EL 7/8J 1-1/16OR 1
8 46496 FTG STR 9/16 J 1/4 NPT 1
9 46416 HOSE 1-1/6 FJ X 1-1/16 FJ 96 (54’s) 2
46846 HOSE 1-1/16 FJ 1-1/16 FJ 91 (43’s) 2
10 46536 HOSE HYD 7/8 FJ 7/8 FJ 15 1
11 46494 FTG HYD 1-1/16 J 7/8 OR 4
12 46455 FTG HYD EL 45 1-1/16 JSW 3
13 46405 HOSE 1 - 1/16 FJ X 1 - 1/16 FJ 53 1
14 46511 FTG EL 1-1/16 J 7/8 OR 2
15 46119 FTG EL 9/16 JSW 9/16 J 2
16 46121 FTG EL 9/16 J 9/16 OR 1
17 46415 HOSE 1-1/16 FJ 1-1/16 FJ 60 1
19 46396 FTG EL 1-1/16 JSW 1
20 46414 FTG STR 3/4 J 9/16 OR 2
21 38531 MOTOR GEAR 1.48 CIR 1
22 46410 HOSE 9/16 FJ 3/4 RJ 88" 2
23 46133 FTG HYD 7/8 J X 7/8 OR 2
24 46181 FTG STR 9/16 J 3/8 NPT 2
25 46378 FTG HYD 1-1/16J 1-1/16 OR 2
26 46490 FTG HYD 9/16 J 3/4 OR 1
27 46389 FTG HYD TEE 9/16 J RUN 1
28 46345 FTG HYD 7/8 J 3/4 NPT 4
29 46526 HOSE HYD 9/16 FJ 9/16 FJ 60 1
30 46529 HOSE HYD 9/16 FJ 9/16 FJ 108 (54’s) 1
46549 HOSE 9/16 FJ X 9/16 FJ 103 (43’s) 1
31 46532 HOSE 7/8 FJ X 7/8 FJ 54 1
32 38518 PUMP GEAR 1.54 CIR 1
33 38776 O-RING 3 - 1/4 ID X 3/32 CS 1
34 46411 FTG HYF 7/8J 1-1/16OR 2
35 46558 FTG EL45 7/8JSW 1
** 38206 HOSE WRAP 2.5 ID POLY (54’s) 72”
HOSE WRAP 2.5 ID POLY (43’s) 60"
A* 80561 HHCS 1/2 - 13 X 1 - 3/4 GR5 2 57 (77)
B 80117 WSHRL 1/2 SPLIT ZN 2 - -
C* 80174 HHSC 3/8 - 16 X 1 GR8 ZN 3 23 (31)
D 80058 WSHRL 3/8 SPLIT ZN 5 - -
E* 80716 HHCS 3/8 - 16 X 1 - 1/4 GR8 ZN 2 23 (31)
* Loctite Required
