3 drum assembly – John Deere rhino pd54 User Manual
Page 63
- 63 -
Item
Part No.
Description
Qty.
REMARK:
Item
Part No.
Description
Qty.
5.3 Drum Assembly
1
42374-2
Drum Weld SD 43
1
42375-2
Drum Weld SD 54
1
42376-2
Drum Weld PD 43
1
42377-2
Drum Weld PD 54
1
2
22748-2
Frame Weld 43
1
22749-2
Frame Weld 54
1
3
22820
Kit Cap & Bearing LH
1
4
22821
Kit Cap & Bearing RH
1
5
29514
Weight Eccentric
1
6
29513
Shaft Eccentric 43
1
29563
Shaft Eccentric 54
1
7
32234
Bearing Eccentric
2
8
29601
Spline Extension
1
9
29980-2
Cover Web Drum
1
10
38507
Seal Shaft
1
11
23015
Kit Wheelmotor & Cap
1
#
32308
Seal Kit for Wheelmotor in 23015
1
12
42232-2
Bracket Weld S-MOUNT RH
2
13
42233-2
Plate MOUNT Wheelmotor
1
14
42234-2
Bracket Weld S-Mount LH
2
15
42236-2
Plate Weld HOUSING
1
16
47281
Shock Mounts (Per Side)
SD43, PD43 (front 2, back 3)
10
SD54, PD54, PDB43 (front 3, back 3)
12
PDB54 (front 3, back 4)
14
17
38531
Motor Gear Eccentric
1
18
32243
Bearing Ball
2
19
42210
Washer 1/8 - 3ID X 3 - 1/2 OD
1
20
46403
FTG Hyd 3/4 NPT X 5/8 H - BARB
2
21
29524
Block Yoke SET
1
22
42490-2
Hose Guard Weld LH
1
42496-2
Hose Guard Weld LH BLADE
1
23
42491-2
Hose Guard Weld RH
1
42497-2
Hose Guard Weld RH BLADE
1
24
29505-2
Hinge Weld ART / OSC
2
25
46521
Plug Pipe 3/4 NPT SKT Hydraulic
2
26
42489-2
Bar Mount Hose Guard
2
27
46131
Hose Hydraulic Low Press 5/8 ID
1
28
46032
Elbow Pipe 3/4 NPT 45 Street
1
29
47305
O-Ring 10 ID X 1/8 CS
2
30
32236
Bearing Flange
4
31
24017
WSHR 2 - 15/16 X 2 - 1/4 ID
2
32
38760
Nilos Ring
1
33
42243-2
Strip Scraper SD 43
2
42242-2
Strip Scraper SD 54
2
29547-2
Scraper PD 43
2
29546-2
Scraper PD 54
2
34^
42494-2
Spacer House Guard
2
35
46042
FTG 164 IB
2
36
47001
Caplug Blue
6
Part Numbers 22820, 22821, 23015 include Item 7.
^ Not required on blade unit
# Not Shown
