Page 89
- 89 -
Item
Part No.
Description
Qty.
REMARK:
Item
Part No.
Description
Qty.
FT. LBS. (Nm)
Torque
5.11 Blade
1
29830-2
Blade Weld 43
1
29820-2
Blade Weld 54
1
3
29819-2
Pivot Weld Blade
2
4
29856-2
Clevis Weld Blade LH
1
5
29857-2
Clevis Weld Blade RH
1
6
29846-2
Skid Weld Blade
1
7
29831-2
Lip Wear Blade 43
1
29817-2
Lip Wear Blade 54
1
8
29741-2
WSHR 2 - 3/4 ID X 17/32 X 1/4 TH
2
9
38561
Clevis 1/4 DIR X 1/4 - 28
1
10
38602
Cable F/R
1
11
46489
Hose 7/8 J X 7/8 J 14
1
12
46133
FTG EL 90 7/8 J X 7/8 OR
1
13
42115-2
Mount Weld Blade Valve
1
14
46544
FTG EL 45 9/16 J
1
15
46490
FTG STR 9/16 J X 3/4 OR
1
16
46528
Hose JSW X 9/16 JSW 48"
2
17
46388
FTG TEE TUBE 9/16J
2
18
46547
Hose 9/16 FJ X 9/16 FJ 60"
2
46551
Hose 9/16 JFJ X 9/16 FJ 56"
-
19
46546
Hose 9/16 FJ X 9/16 FJ 70"
2
46552
Hose 9/16 FJ X 9/16 FJ 66"
-
20
46120
FTG EL90 9/16 J X 3/8 NPT
2
21
46369
FTG EL 45 X 3/8 NPT X 9/16 J
2
22
46444
Cylinder Tie Rod 2 X 8
2
44203
Pin Clevis 1"
4
44204
RUE RING 1"
4
23
42160-2
ADJ Blade Valve
2
25
46462
FTG EL90 7/8 JSW
1
26
46124
FTG STR 7/8 J X 7/8 OR
1
27
38526
Valve CONTROL
1
28
38828
Hose Wrap 1.5 ID POLY
44"
29
38828
Hose Wrap 1.5 ID POLY
44"
A
80051
NUTNY 1/2 - 13 ZN
22
57
(77)
B
80343
WSHR 1/2 SAE ZN
30
-
-
C
80405
HHSC 1/2 - 13 X 2 - 3/4 GR5 ZN
8
57
(77)
D
80672
HHCS 3/4 - 10 X 3 GR8 ZN
4
282
(382)
E
80671
WSHRL 3/4 SPLIT ZN
4
-
-
F
80677
CRBLT 1/2 - 13 X 1 - 1/2 ZN
14
-
-
G
80117
WSHRL 1/2 SPLIT ZN
2
-
-
H
80378
HHCS 1/2 - 13 X 1 GR5 ZN
2
57
(77)
I
80085
HWHTB 5/16 - 18 X 1 ZN
2
18
(18)
J
80348
WSHR 5/16 WROT ZN
4
-
-
K
80070
PPHMS 10 - 24 X 1 ZN
1
-
-
L
80114
NUTNY 5/16 - 18 ZN
2
-
-
M*
80170
HHCS 5/16 - 18 X 2 - 1/2 GR5 ZN
2
13
(18)
N
80058
WSHR 3/8 SPLIT ZN
2
-
-
O*
80088
HHCS 3/8 - 16 X 1 - 1/4 GR8 ZN
2
23
(31)
P
80346
WSHR #10 SAE ZN
2
-
-
Q
80693
NUTNY #10 - 24 ZN
1
-
-
* Loctite Required
