Appendix ii: block diagram – Intel Arima LH500 User Manual
Page 76
76
APPENDIX II: Block Diagram
For your convenience, we have included this block diagram to show the internal design
of the motherboard in order to better aid you in troubleshooting. This diagram shows the
bus and the channel of data flow. A good understanding of this diagram can help you
clarify the configuration choices for your own optimization.
