58
3.5.5 Console Redirection Sub Menu
The Console Redirection Sub Menu looks like the following:
PhoenixBIOS Setup Utility
Advanced
Console Redirection Item Specific Help
Com Port Address [Disabled]
Baud Rate [19.2K]
Console Type [PC ANSI]
Flow Control [CTS/RTS]
Console connection [Direct]
Continue C.R. after POST [Off]
If enabled, it will use
a port on the
motherboard.
F1 Help ↑↓ Select Item -/+ Change Values F9 Setup Defaults
ESC Exit ←→Select Menu Enter Select►Sub-Menu F10 Save and Exit
The following table shows the items that you can customize on the Console Redirection sub-menu page:
Item Options Description
Com Port Address Disabled
On-board COM A
On-board COM B If enabled, it will use a port on
the motherboard.
Baud Rate 300
1200
2400
9600
19.2K
38.4K
57.6K Enables the specified baud rate.
Console Type VT100
VT100, 8bit
PC-ANSI, 7bit
PC-ANSI
VT100+
VT-UTF8 Enables the specified console
type.
Flow Control None
XON/XOFF
CTS/RTS Enables flow control
Console connection Direct
Via modem Indicate whether the console is
connected directly to the system
or a modem is used to connect.
Continue C.R. after POST Off
On Enables Console Redirection
after OS has loaded.
