Intel Arima LH500 User Manual
Page 50
50
Transfer Mode
Standard
Fast PIO 1
Fast PIO 2
Fast PIO 3
Fast PIO 4
FPIO 3/ DMA 1
FPIO 4/ DMA 2
Select the method for moving
data to/from the drive. Autotype
the drive to select the optimum
transfer mode.
Ultra DMA Mode
Disabled
Mode 0
Mode 1
Mode 2
Mode 3
Mode 4
Mode 5
Selects the Ultra DMA mode
used for moving data to/from the
drive. Autotype the drive to
select the optimum transfer
mode.
All the IDE Channel sub-menus and SATA sub-menus
have the same sub-menu layout as the one shown above.
.
