Impex IGS 16 User Manual
Igs 16 personal trainer, Model igs 16, Impex fitness products
Table of contents
Document Outline
- BEFORE YOU BEGIN...................................................................................... 1
- IMPORTANT SAFETY NOTICE....................................................................… 2
- HARDWARE PACK…….......….....................................................................… 3
- ASSEMBLY INSTRUCTIONS........................................................................... 7
- PARTS LIST...................................................................................................... 29
- RESISTANCE CHART…………........................................................................ 31
- WARRANTY.................................................................................................…. 32
- ORDERING PARTS.......................................................................................… 32
- HARDWARE PACK
- HARDWARE PACK
- HARDWARE PACK
- HARDWARE PACK
- Place the Main Base Frame (#2) on a flat surface.
- Attach two Pulleys (#84) to the open oblique pulley brackets on the center of the Main Base Frame. Secure each Pulley with one M10 x 2” Allen Bolt (#102), two Ø ¾” Washers (#118), and one M10 Aircraft Nut (#125).
- Attach four Pulleys (#84) to the other four open brackets on the Main Base Frame. Secure each Pulley with one M10 x 1 ¾” Allen Bolt (#101), two Ø ¾” Washers (#118), and one M10 Aircraft Nut (#125).
- Slide a Ball Stopper (#70) onto the 161” Upper Cable (#52). Slide and Pull the Cable Strap Bracket (#45) onto the Cable. Secure the Bracket with a M8 x 1 ¼” Allen Bolt (#110) and M8 Aircraft Nut (#124).
- Attach the tip of the Upper Cable to the Pulley on the front of the Upper Frame (#5). Insert the Cable into the Frame through the tube to the second opening. Remove the Pulley to get the Cable out then reinstall the Pulley.
- Draw the Cable around the Pulley then down to the right Pulley on the back of the Bench Press Base (#32). Draw the Cable around the right Pulley then to the Pulley on the front of the Front Vertical Beam (#3).
- Draw the Cable around the Pulley then back to the left Pulley on the back of the Bench Press Base (#32).
- Draw the Cable around the left Pulley then to the Pulley in the upper open slot on the Front Vertical Beam (#3).
- Draw the Cable underneath the Pulley then pull upward to the first right Pulley underneath the Upper Frame. Draw the Cable over the Pulley to the second right Pulley underneath the Upper Frame.
- Draw the Cable over the Pulley then pull downward. Attach the Cable to the upper Pulley on an Angled Double Floating Pulley Bracket (#26) installed in Step12. Attach the Bracket underneath the Pulley Pre-tensioner (#24).
- Draw the Cable underneath the Pulley then pull upward to the Pulley on the Adjustable Single Pulley Bracket installed in Step-7G. Let the Double Floating Pulley Bracket (#26) hanging for now.
- Draw the Cable around the Pulley then pull downward to the Selector Rod (#36).
- Attach the end of the Cable to a M12 x 1” Split Bolt (#42). Thread the Split Bolt through a Ø 1” Spring Washer (#116) and the ring on the Weight Plate Selector Pin (#72) into the Selector Rod (#36).
- Connect the Lat Bar (#17) to the Cable Strap Bracket with a Hook (#41).
- Place the Lat Bar onto the Lat Bar Holder.
- DIAGRAM 13
- 20
- Slide a Ball Stopper (#70) onto the 262” High-Low Cable (#53). Slide and Pull the Cable Strap Bracket (#45) onto the Cable. Secure the Bracket with a M8 x 1 ¼” Allen Bolt (#110) and M8 Aircraft Nut (#124).
- DIAGRAM 14
- 22
- 25
- PARTS LIST
- KEY NO. DESCRIPTION Q’ty
- Station
- High Low Cable
- Station
