LV-671 User’s Manual Hardware Setup
Expansive Interface
34
2.13
The board comes with one slim type PCI slot and one optional Mini-AGP or Mini-PCI
interface. The slim PCI slot supports up to 2 PCI devices through an optional riser card. For
Mini-PCI interface, you can obtain a wireless LAN card for potable system. For Mini-AGP
interface, you can obtain an extended graphic card to improve the onboard graphics
performance.
Mini-AGP
Mini-PCI
Slim-PCI
Optional PCI Riser Card
Optional Mini-PCI Wireless LAN Card
Optional MA-ATI Mini-AGP Card
