4 Page 14
Page 14
LV-671 User’s Manual
Block Diagram
14
1.4
Intel Pentium M processor with FC-PGA2/FC-BGA2
855GME
CRT
LCD
LVDS
400MHz FSB
1 x 184-pin
DIMM
Up to 1GB
DDR266/333
ICH4
ATAPI Devices
USB Devices
UltraATA100
USB2.0
Audio
AC97 Codec
PCI Bus
Gigabit Ethernet
Controller
LPC
IrDA
PS/2
COM Port
Parallel
Port
Floppy
Mini-AGP
LVDS
AGP 4x
33MHz
Compact Flash
DVO B/C
480Mb/s
Slim PCI
Mini-PCI
PCMCIA
