LV-671 User’s Manual
Product Specification 12
Power and Environment
Power
Requirement One external 19V/12V (auto switching) DC Adapter connector on
rear panel
4-pin onboard 12V P4 4-pin power connector
(Two power resources selectable for each)
Input Voltage
Range 11V ~ 13V for 12V power supply
16V ~ 20V for 19V power supply
Input Current 12V/60W (with one 5.25” CDROM and 3.5” HDD)
19V/60W (with one 5.25” CDROM and 3.5” HDD)
Dimension 170 (L) x 170 (H) mm, Mini-ITX form factor
Temperature Operating within 0 ~ 60
o
C (32 ~ 140
o
F)
Storage within -20 ~ 85
o
C (-4 ~ 185
o
F)
Ordering Code
LV-671-MA Mini-ITX Socket 479 Pentium-M processor Motherboard
with Intel Extreme VGA, LAN, 5.1-CH/SPDIF Audio,
Hi-Speed USB 2.0, mini-AGP socket and LVDS interface.
LV-671-MP Mini-ITX Socket 479 Pentium-M processor Motherboard
with Intel Extreme VGA, LAN, 5.1-CH/SPDIF Audio,
Hi-Speed USB 2.0, mini-PCI socket and LVDS interface.
LV-671-MAPM11 Same as LV-671-MA and with onboard Intel Pentium M 1.1GHz
processor for ULV/LV version.
LV-671-MPPM11 Same as LV-671-MP and with onboard Intel Pentium M 1.1GHz
processor for ULV/LV version.
LV-671-MACM6 Same as LV-671-MA and with onboard Intel Celeron M 600MHz
processor for ULV/LV version.
LV-671-MPCM6 Same as LV-671-MP and with onboard Intel Celeron M 600MHz
processor for ULV/LV version.
For further product information please visit the website at http://www.commell.com.tw
