LV-671 User’s Manual
10
1.2
General Specification
Form Factor
Mini-ITX motherboard at 170 x 170 mm (L x W)
CPU
Package: 478 pin PGA/ 479 pin BGA
L2 Cache: 512KB/1MB/2MB
FSB: 400MHz
( The Intel® Celeron® M Processor 4xx series have been
designed to work with the Mobile Intel® 945 Express Chipset
Family only .)
Memory
1GBytes DDR200/266/333 SDRAM on one 184-pin DIMM socket
ECC memory is supported
Chipset
Intel 82855GME GMCH and 82801DB ICH4
BIOS
Phoenix-Award v6.00PG 4Mb PnP flash BIOS
Green Function
Power saving mode includes doze, standby and suspend modes.
ACPI version 1.0 and APM version 1.2 compliant
Watchdog Timer
System reset programmable watchdog timer with 1 ~ 255
sec./min. of timeout value
Real Time Clock
Intel ICH4 built-in RTC with lithium battery
Enhanced IDE
PCI enhanced IDE interface supports dual channels and up to 4
ATAPI devices at UltraATA/100
One 40-pin and one 44-pin IDE port
DiskOnModule (DOM) embedded flash disk up to 1GBytes
Multi-I/O Port
Chipset
Intel 82801DB ICH4 (USB) and Winbond W83627HF-AW LPC
Super I/O controller
Serial Port
Two external RS-232 serial port with 16C550 compatible UART
and 16 bytes FIFO
USB Port
Six Hi-Speed USB 2.0 ports with 480 Mbps of transfer rate
Two external and four internal USB ports
Parallel Port
One external bi-direction parallel port with SPP/ECP/EPP mode
Floppy Port
One slim-type FDD port supports up to two FDD
IrDA Port
One IrDA compliant Infrared interface supports SIR
K/B & Mouse
External PS/2 keyboard and mouse ports on rear I/O panel
GPIO
One 20-pin Digital I/O connector with 15-bit programmable I/O
interface
Card Bus
PCMCIA
One PCMCIA Type I/II slot
VGA Display Interface
Chipset
Intel 855GME GMCH built-in Intel Extreme Graphics 2
With 266 MHz VGA core and 256-bit 3D engine
