Supplied Accessories
Make sure you have the following accessories:
Plug the supplied power cord into this AC INLET.
• Do not use a power cord other than the one supplied
with the DTR-10.5. The power cord supplied is
designed for use with the DTR-10.5 and should not
be used with any other device.
• Never have the power cord disconnected from the
DTR-10.5 while the other end is plugged into the
wall outlet. Doing so may cause an electric shock.
Always connect by plugging into the wall outlet last
and disconnect by unplugging from the wall outlet
first. Remote Controller & Three Batteries (AA/R6)
AM Loop Antenna
Indoor FM antenna
(connector type varies from country to country)
Speaker Labels
Terminal Wrench
A wrench to screw/unscrew the speaker terminal cap.
Power Cord ( The shape of the plug varies depending on
the region where the model is intended.)
