Installation and Connections
Connecting
-compatible AV Components
The
terminal on the DTR-10.5 is for connecting
other Integra/Onkyo components equipped with the
same
terminal. When a component is connected to
the
terminal, it can be operated by the remote
controller supplied with the DTR-10.5. In addition,
when you connect a component to the
terminal, you
can also perform the system operations given below.
Power on/ready function
When the DTR-10.5 is in the standby state, if an
-
connected component is turned on, the DTR-10.5 also
turns on and the input source selected at the DTR-10.5
automatically switches to that component.
Be aware that this function will not work if the power cord
for the
-connected component is connected to the AC
OUTLET on the DTR-10.5, or if the DTR-10.5 has
already been turned on.
Direct change function
When the play button is pressed on an
-connected
component, the input source selected at the DTR-10.5
automatically changes to that component.
Power off function
When the DTR-10.5 is placed in the standby state, all
-connected components are also automatically put
into the standby state.
Also, if you press the [On] button on the DTR-10.5
remote controller while the DTR-10.5 is turned on, all
-connected components (DVD players, CD players,
MD recorders, tuners, etc.) are also turned on.
To connect components using the
terminal, simply
connect a remote control cable from this
terminal to
the
terminal of the other component. An
remote
control cable with a 1/8 inch (3.5 mm) miniature two-
conductor plug comes with every cassette tape deck,
compact disc player, MD recorder, and DVD player that
has an
terminal.
• When performing operations with
-connected
components using the
system, do not use the
remote zone (Zone 2/Zone3).
• For remote control operation, the audio connection
cables must also be connected.
• If a component has two
terminals, you can use
either one to connect to the DTR-10.5. The other one
can be used to daisy chain with another component.
• With Integra DVD players, you can enter the pre-
program code so that you can operate the DVD player
directly with the remote controller without connecting
the
terminals (See page 129).
E
GND
RS
232
IR IN
+
12 V DC PWR SUPPLY
MAIN
GND
ZONE
3
ZONE
2
20mA MAX.
12 V
TRIGGER
OUT
E
MODEL NO.
DTR-10.5
GND
C
D
E
B
A
12 V
TRIGGER OUT
100mA MAX.
100mA MAX.
100mA MAX.
TOTAL
100mA MAX.
200mA MAX.
UDD
AC INLET
FRONT L
CENTER
FRONT R
SURR BACK L
(
ASSIGNABLE
)
URR R
SURR L
FRONT R (BTL)
FRONT L (BTL)
(SINGLE)
AC 120V 60Hz
SWITCHED
120W 1A MAX.
AC OUTLET
SPEAKERS A
SPEAKERS B
2
2
1
6
6
5
5
4
4
3
3
2
2
1
1
OPTICAL
COAXIAL
AUDIO IN
1
3
2
1
PH
2
3
9
8
7
6
5
4
4
5
R
L
L
R
L
R
R
L
G
IN
1
IN
2
HDMI
S VIDEO
VIDEO
IN
IN
IN
1
IN 2
3
2
1
Y
P
B
P
R
COMPONENT
VIDEO
IN
3
6
5
4
Y
P
B
P
R
2
1
4
3
ANTENNA
FM
75
SURR BACK R
(
ASSIGNABLE
)
DIGITAL IN
DIGITAL IN
L
R
S VIDEO
S VIDEO
VIDEO
VIDEO
C
D
OUT
OUT
F
L
OUT
I
H
OUT
OUT
J
K
OUT
1
AM
1
SBR
SBL
SR
SL
SUB
C
FR
FL
SBR
SBL
SR
SL
SUB
C
FR
FL
MULTI
- CH
IN 1
MULTI
- CH
IN 2
OUT
Y
P
B
P
R
Y
P
B
P
R
COMPONENT VIDEO
IN
(HD/BNC)
REMOTE
CONTROL
L
R
ANALOG
OUTPUT
AUDIO IN
R
4
L
REMOTE
CONTROL
Integra DVD player
Remote
control
cable
Connections for Remote Control (
)
DTR-10.5
Ex: Integra/Onkyo CD
player
connector
connector
Ex: Onkyo cassette tape
deck
Remote control cable
