Quick Start Guide—Intel

®

IXDP465 Development Platform

AN

Intel

®

IXDP465 Development Platform

May 2005

Order Number: 305825, Revision: 002

21

9.0

Preparing the Platform for Initial Use

After unpacking the board and before powering on the board, the IXDP465 development platform
needs to be prepared for first time use.

To prepare the platform, follow these steps:

1. Verify that all default switch settings in

Table 3 on page 10

are checked off.

2. Verify that all default jumper settings in

Table 4 on page 12

,

Table 5 on page 15

, and

Table 6

on page 17

are checked off.

3. Confirm that either one of two boot options is selected, controlled by jumper(s) JP127 (A24)

and JP128 (A23) as shown in

Figure 3 on page 14

.

• For RedBoot, install both JP127 and JP128.

• For VxWorks, install JP127 only.

4. Install the Intel

®

PRO/100+ Adapter into PCI slot 0. Connect the straight Ethernet cable

provided with the IXDP465 development platform and connect to a hub.

Note:

An alternative option is to use a cross-over Ethernet cable between the Intel

®

PRO/100+ Adapter and the host system.

5. Connect the serial cable between COM1 on the host system:

• to UART0 for Linux* developers

• to UART1 for VxWorks* developers

Table 8

shows the UART serial communication values.

.

10.0

Starting the Platform

To start the platform, follow these steps:

1. Verify that the power switch is in the OFF position on the Autec Power Systems* power

supply provided with the IXDP465 development platform.

2. The power module plugs into the baseboard through a standard ATX 20-pin power supply

connector (P1). Connect the ATX power supply cable to ATX connector on the IXDP465
development platform.

3. Power on the board by flipping the black switch on the power supply.

4. Verify that all LED illuminations match the defaults settings listed in

Table 7 on page 19

.

Table 8.

UART Communications Configuration

Parameter

Linux* Value

VxWorks* Value

Port

UART0

UART1

Bits per Second

115,200

9,600

Data Bits

8

8

Parity

None

None

Stop Bit

1

1

Flow Control

None

None
