Intel
®
IXDP465 Development Platform—Quick Start Guide
May 2005
Intel
®
IXDP465 Development Platform
AN
14
Order Number: 305825, Revision: 002
Figure 3.
Intel
®
IXDP465 Baseboard Jumper Locations
B5021-01
MII / SMII / UTOPIA
WRITE
UTOPIA
JP3
ETH A
JP2
SMII
JP1
ETH C
ETH B
JP4
JP11
JP9
A23
A24
JP128
JP127
JP126
Installed =
NOT Installed =
KEY:
