Page 15
Quick Start Guide—Intel
®
IXDP465 Development Platform
AN
Intel
®
IXDP465 Development Platform
May 2005
Order Number: 305825, Revision: 002
15
7.2
Intel
®
IXP465 Network Processor/DDR Module Jumpers
identifies the jumper locations and
describes the jumper settings for the Intel
®
IXP465 Network Processor/DDR module.
Table 5.
Intel
®
IXP465 Network Processor/DDR Module Jumper Descriptions and Default
Settings
Board Location
Ref ID
Jumper Description
for Installed State
Default Settings
Quick Start
Check?
SCL
P4
Selects I2C pin, instead of GPIO
Shunt 1-2.
F
SDA
P2
Selects I2C pin, instead of GPIO
Shunt 1-2.
F
IXP 3.3V
JP45
Enables monitoring of +3.3V current
Not installed.
F
XTAL OUT
JP50
Reserved
Not installed.
F
XTAL IN
JP49
Reserved
Not installed.
F
BYPSSCLK
JP41
Connects oscillator to OSC_IN
Installed.
F
REFCLK
JP1
Enables Spreadspectrum clock
reference
Not installed.
F
SSCLK
JP2
Connects Spreadspectrum clock to
OSC_IN
Not installed.
F
ENSSCLK
JP44
Enables Spreadspectrum clock output
Not installed.
F
IXP COREV
JP47
Enables monitoring of +1.3V/+1.4V
current
Not installed.
F
667 MHz
JP48
Enables selection of +1.3V as core
voltage, instead of +1.4V as required
for 667 MHz operation
Installed.
F
IXP 2.5V
JP46
Enables monitoring of +2.5V current
Not installed.
F
