Intel, Figure 4, Ee figure 4) – Intel IXDP465 User Manual
Page 16
Intel
®
IXDP465 Development Platform—Quick Start Guide
May 2005
Intel
®
IXDP465 Development Platform
AN
16
Order Number: 305825, Revision: 002
Figure 4.
Intel
®
IXP465 Network Processor/DDR Module Jumper Locations
B5036-01
JP46
IXP 2.5V
667 MHz
JP47
IXP COREV
EN SSCLK
SSCLK
REFCLK
BYP SSCLK
(installed by default)
XTAL IN
XTAL OUT
IXP 3.3V
SDA - P2
SCL - P4
GPIO
I2C
IXP
