IXDP465 Development Platform—Quick Start Guide
May 2005 Intel
®
IXDP465 Development Platform AN
10 Order Number: 305825, Revision: 002
Table 3. Intel
®
IXDP465 Development Platform Switch Descriptions and Default Settings
Board Location
(See Figure 2)
Ref ID Switch Description Default Settings
Quick
Start
Check?
GPIO LED Switches SW1
Select individual LED illumination
settings of all odd GPIO signals All odd GPIO illuminated.
Switch in ON position.
F
GPIO LED Switches SW2
Select individual LED illumination
settings of all even GPIO signals All even GPIO illuminated.
Switch in ON position.
F
Expansion Bus
Address Strap
Switches
SW3
Select floating or pull down straps
for EX_ADDR[8:1] signals All EX_ADDR floating.
Switch in OFF position.
F
Expansion Bus
Address Strap
Switches
SW4
Select floating or pull down straps
for EX_ADDR[16:9] signals All EX_ADDR floating.
Switch in OFF position.
F
Expansion Bus
Address Strap
Switches
SW5
Select floating or pull down straps
for EX_ADDR[24:17] signals All EX_ADDR floating.
Switch in OFF position.
F
