7.3
Intel
®
IXPETM465 Ethernet PHY Mezzanine Card Jumpers
identifies the jumper locations and
describes the jumper settings for the Ethernet
card.
Table 6.
Intel
®
IXPETM465 Ethernet PHY Mezzanine Card Jumper Descriptions and Default
Settings
Board Location
Ref ID
Jumper Description
for Installed State
Default Settings
Quick Start
Check?
GND
JP1
GND
Not installed.
F
GND
JP3
GND
Not installed.
F
A0
JP2
PHY Address A0 for MII-0 NPE-B
Ethernet mezzanine slot
Shunt 2-3.
F
A1
JP5
PHY Address A1 for MII-0 NPE-B
Ethernet mezzanine slot
Shunt 2-3.
F
A2
JP6
PHY Address A2 for MII-0 NPE-B
Ethernet mezzanine slot
Shunt 2-3.
F
A3
JP7
PHY Address A3 for MII-0 NPE-B
Ethernet mezzanine slot
Shunt 2-3.
F
A4
JP8
PHY Address A4 for MII-0 NPE-B
Ethernet mezzanine slot
Shunt 2-3.
F
GND
JP4
GND
Not installed.
F
