A-13
Realtek ALC850 Audio
n 4-Channel Mode for 4-Speaker Output
Back Panel
Description:
Connect two speakers to back
panel
’s front-channel Line Out
connector and two speakers to
t he r eal- c h an n el L in e O u t
connector.
4-Channel Analog Audio Output
1 Line In
2 Line Out (Front channels)
3 MIC
4 Line Out (Rear surround channels)
5 Line Out (Center and Subwoofer channel, but no functioning in this mode)
6 Line Out (Side surround channels, but no functioning in this mode)
3
1
2
6
4
5
