M S-7236 M ainboard
2-8
Installing DDR II Modules
1.The DDR II DIMM has only one notch on the center of module. The module will only fit
in the right orientation.
2.Insert the DIMM memory module vertically into the DIMM slot. Then push it in
until the golden finger on the memory module is deeply inserted in the socket.
3.The plastic clip at each side of the DIMM slot will automatically close.
Volt Notch
You can barely see the golden finger if the module is properly
inserted in the socket.
Impor tant
