GA-G1975X Motherboard - 92 -
English
4/4.1 Channel Speaker Configurations
STEP 2:
Connect the Surround-Kit to the SUR_CEN connector located on the motherboard. Then the installation
is completed.
Front Speaker Out Rear Speaker Out
STEP 1 :
Connect the 4/4.1 channel speakers to the Line
Out (Front Speaker Out) jack in the back panel and
the Rear Speaker Out jack on the Surround Kit.
STEP 2:
In the Speaker Selection tab of Creative Speaker
Settings, click 4/4.1 Speakers in the Speaker/
Headphone Selection list. After completion, you
can click the Channel/Noise button to check
whether the speaker selection corresponds to your
speaker configuration.
